Airtac STWB Slide Table Cylinder STWB20X200S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB20X200S Slide Table Cylinder Specifications
- Model: STWB20X200S
- Type: Guided rod slide table cylinder with integrated linear guide
- Bore size: 20mm
- Stroke: 200mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston speed: 50–800 mm/s
- Repeat positioning accuracy: ±0.01mm
- Maximum lateral load: 14.7N
- Maximum moment load: 3.9N·m
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR + PU hybrid seals
- Weight: 1.54kg (excluding accessories)
- Dimensions: 300mm(L) × 50mm(W) × 40mm(H) (fully extended)
- Rod material: Hard chrome-plated steel rod
- Mounting options: Horizontal/Vertical with side or base mounting holes
- Accessory ready: Magnetic sensor groove (M5 slot)
Precision-guided cylinder combining pneumatic actuation with linear rail stability, featuring zero backlash movement and 0.1μm surface roughness on guide rails. Anti-creep design maintains positional accuracy under vibration. Pre-lubricated for 3,000km service life (maintenance-free). Requires 5μm filtered air with ISO VG32 oil mist lubrication.
- PCB component insertion machines (vertical Z-axis movement)
- Lens polishing equipment precision positioning
- Automated optical inspection (AOI) systems
- Pharmaceutical blister packaging alignment
- Semiconductor wafer handling robots
Installation protocol:
Torque mounting bolts to 3.5N·m max. Align guide rail parallelism within 0.05mm/m.
For vertical mounting, install air vent downward. Lubricate guide rails every 500km
operation using ISO VG68 grease.
| Property | Property Value |
|---|---|
| sku | STWB20X200S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <200mm> |
