Airtac STWB Slide Table Cylinder STWB20X50S
$200.03
Regular price
$207.53
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
STWB20X50S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Both the slide block and main body support mounting for flexible installation;
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
Installation note:
Ensure rail alignment within 0.05mm/m using precision level. Use SHCS bolts (M5x0.8, 2Nm torque)
at all mounting points. Lubricate guide shafts with ISO VG32 hydraulic oil during initial setup.
Critical parameters:
Max side load: 15N
Allowable moment: M1=3.5N·m, M2=2.0N·m
Do NOT exceed 90% stroke limit during continuous operation
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB Series Slide Table Cylinder STWB20X50S Specifications
- Model: STWB20X50S
- Type: Twin-shaft slide table cylinder (Double rail guided)
- Bore size: 20mm
- Stroke: 50mm
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -10℃ to 80℃
- Cushion type: Adjustable pneumatic cushion (both ends)
- Port size: M5x0.8 (Standard) / Optional NPT1/8
- Piston material: Aluminum alloy hard anodized
- Rod material: SUS304 stainless steel
- Seal type: NBR rubber (Oil-resistant)
- Repeat positioning accuracy: ±0.05mm
- Max sliding speed: 500mm/s
- Weight: 1.25kg (With standard accessories)
- Dimensions: 148mm(L) × 45mm(W) × 50mm(H)
- Protection rating: IP54 (Dust-proof & splash-resistant)
Precision linear actuator combining cylinder and linear guide functions, featuring dual stainless steel shafts for enhanced rigidity. Integrated mounting slots allow direct attachment of workpieces or tooling plates. Lubrication-free design with self-compensating wear resistance.
Typical Applications:
- PCB component insertion machines
- Laser marking positioning stages
- Automated inspection jigs
- Semiconductor wafer handling
- Pharmaceutical blister packaging
- Robotic end-effector tool changers
Installation note:
Ensure rail alignment within 0.05mm/m using precision level. Use SHCS bolts (M5x0.8, 2Nm torque)
at all mounting points. Lubricate guide shafts with ISO VG32 hydraulic oil during initial setup.
Critical parameters:Max side load: 15N
Allowable moment: M1=3.5N·m, M2=2.0N·m
Do NOT exceed 90% stroke limit during continuous operation
| Property | Property Value |
|---|---|
| sku | STWB20X50S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <50mm> |
