Airtac STWB Slide Table Cylinder STWB20X75S
Genuine AirTAC slide cylinder, order code STWB20X75S from the STW range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- MountingBody fixed (STWB)
- BoreØ20 mm
- Stroke75 mm
- ActionDouble acting, twin rod
- CushionHydraulic shock absorber
- Ø1050.3 N at 0.5 MPa · port M5×0.8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac STWB Slide Table Cylinder STWB20X75S
This code orders the STW slide cylinder fixed through its body (B) with a Dia 20 bore and an extended 75 mm stroke. The longer travel gives 25 mm more reach than the 50 mm version while the theoretical force stays at 201.1 N at 0.5 MPa, and hydraulic shock absorbers still absorb both stroke ends.
Because 75 mm remains within the 100 mm threshold, stroke tolerance is the tighter +1.0 / 0 mm band. Twin rods limit rotation to 0.05 deg so the slide plate stays aligned over the longer span, while the built-in magnet with its sensor rail and three sets of M5x0.8 ports simplify position feedback and piping.
Airtac STWB Slide Table Cylinder STWB20X75S Technical Specifications
| Order code | STWB20X75S |
|---|---|
| Product | Slide Cylinder |
| Mounting | Body fixed (STWB) |
| Bore | Ø20 mm |
| Stroke | 75 mm |
| Action | Double acting, twin rod |
|---|---|
| Cushion | Hydraulic shock absorber |
| Ø10 | 50.3 N at 0.5 MPa · port M5×0.8 |
| Ø16 | 122.5 N at 0.5 MPa · port M5×0.8 |
| Ø20 | 201.1 N at 0.5 MPa · port M5×0.8 |
| Ø25 | 289.8 N at 0.5 MPa · port PT1/8 |
| Ø32 | 490.1 N at 0.5 MPa · port PT1/8 |
| Fluid | Air (filtered by 40 µm element) |
| Operating pressure | 0.2-1.0 MPa (Ø10), 0.15-1.0 MPa (Ø16-32) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to +70 °C |
| Speed | 30-500 mm/s |
| Stroke tolerance | +1.0 / 0 mm (≤100), +1.5 / 0 mm (>100) |
| Anti-rotation | ±0.1° (Ø10), ±0.05° (Ø16, 20), ±0.03° (Ø25, 32) |
| Port | M5×0.8 (Ø10-20), PT1/8 (Ø25, 32) |
Source: AirTAC Products Catalog 2026A (PDF01-P0547..P0548), STW series specifications, theoretical force, strokes and ordering code.
How to choose
Choose STWB20X75S when stroke, not force, is the deciding dimension: STWB20X50S halves the travel and STWB20X100S doubles it, and STWA20X75S switches to end-plate fixing. Force-wise the Dia 16 STWB16X75S drops to 122.5 N while the Dia 25 STWB25X75S raises it to 289.8 N, so this bore sits mid-range.
Applications
Extend-to-grip station
The 75 mm reach lets jaws or a suction plate enter a nest that a 50 mm slide cannot clear, then retract fully out of the robot's path.
Cross-transfer between conveyors
Body fixing suits a bracket under the transfer line, and the extra travel bridges the gap between two lanes without repositioning the whole unit.
Guided alignment slide
0.05 deg anti-rotation over 75 mm keeps a guide or aligner plate parallel to the machine datum across the full stroke.
FAQ
What are the key figures of the STWB20X75S?
Dia 20 bore, 75 mm stroke, body-fixed (B) mounting, magnet built in (S), M5x0.8 ports, theoretical force 201.1 N at 0.5 MPa, operating pressure 0.15-1.0 MPa, speed 30-500 mm/s, temperature -20 to +70 C, anti-rotation 0.05 deg, stroke tolerance +1.0 / 0 mm.
Does the 75 mm stroke change the port size or the pressure range?
No. Stroke length does not alter the ports or the pressure band: Dia 20 uses M5x0.8 ports and works at 0.15-1.0 MPa on air filtered to 40 um. Only strokes above 100 mm would relax the stroke tolerance to +1.5 / 0 mm.
