Airtac STWB Slide Table Cylinder STWB25X100S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB Series Slide Table Cylinder STWB25X100S Specifications
- Model: STWB25X100S
- Type: Guided slide table cylinder with linear guide
- Bore size: Ø25mm
- Stroke: 100mm (standard range: 25-500mm)
- Mounting style: Side flange / Base mounting options
- Operating pressure: 0.1-0.8 MPa
- Cushioning: Elastic buffer + shock absorber
- Repeat positioning accuracy: ±0.01mm
- Temperature range: -10℃ to 60℃
- Port size: M5x0.8 (G1/8 optional)
- Seal material: NBR (nitrile rubber)
- Guide type: Dual linear ball bearings
- Max sliding speed: 0.5 m/s
- Protection rating: IP40 (dust protected)
- Weight: 1.8kg ±5%
- Dimensions (L×W×H): 205mm × 45mm × 34mm (including mounting brackets)
Precision-guided pneumatic slide cylinder combining cylinder thrust with linear bearing stability. Features hardened steel guide rods (HRC60+) and aluminum alloy body with black anodized finish. Integrated T-slot design allows direct mounting of workpieces. Requires filtered air (5-50μm) with 1-2 drops of ISO VG32 oil per 10m³ air.
- Precision alignment in semiconductor wafer handling
- Vertical Z-axis movement in automated test equipment
- Part positioning in CNC machine tool changers
- Linear indexing in pharmaceutical blister packaging
- Optical component adjustment stages
Installation tip:
Maintain 0.02mm parallelism tolerance between cylinder axis and load direction.
Use anti-vibration pads when mounting on aluminum frames. Lubricate guide rails
every 500km travel distance using ISO 32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | STWB25X100S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 100mm |
