Airtac STWB Slide Table Cylinder STWB25X150S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB25X150S Slide Table Cylinder Specifications
- Model: STWB25X150S
- Type: Guided slide table cylinder with linear guide rail
- Bore size: 25mm
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.05-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Horizontal or vertical via 4x M5 threaded holes
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body, hardened steel piston rod
- Repeat positioning accuracy: ≤±0.02mm
- Max speed: 500mm/s (with cushioning)
- Port size: M5x0.8 (Rc1/8 compatible)
- Weight: 1.8kg (with standard fittings)
- Dimensions: 270mm(L) × 50mm(W) × 50mm(H) (stroke-included length)
- Guide rail type: Dual-axis cross-roller structure
- Lubrication: Pre-lubricated (relubrication interval: 2,000km travel)
High-precision guided cylinder with integrated linear motion system, featuring exceptional moment resistance and positional stability. The hardened steel guide rails and optimized seal arrangement ensure minimal drift during high-cycle operations. Includes magnetic piston for sensor mounting (sensor not included).
- Precision alignment in semiconductor wafer handling
- Vertical Z-axis movement in CNC tool changers
- Automated optical inspection (AOI) equipment positioning
- High-speed pick-and-place operations with lateral stability
- 3D printing bed leveling mechanisms
Installation note:
Apply anti-vibration washers when mounting to aluminum frames. For vertical installations exceeding 45° angle,
use external braking system during power loss. Lubricate guide rails every 500,000 cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | STWB25X150S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 150mm |
