Airtac STWB Slide Table Cylinder STWB25X175S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB Series Slide Table Cylinder STWB25X175S Technical Details
- Model: STWB25X175S
- Series: STWB (Compact Slide Table Actuator)
- Bore size: 25mm
- Stroke: 175mm
- Mounting type: Standard base mounting with precision guide rails
- Buffer type: Adjustable pneumatic cushioning (both ends)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: 1/8" NPT (M5 optional)
- Lubrication: Non-lubricated (Oil-free operation supported)
- Material:
- Cylinder tube: Hard anodized aluminum alloy
- Piston rod: Stainless steel (SUS304)
- Seals: NBR rubber
- Max speed: 500 mm/s
- Repeat positioning accuracy: ±0.1mm
- Weight: 1.8 kg (with standard fittings)
- Dimensions: 225mm(L) × 40mm(W) × 40mm(H) (total length = stroke + 50mm)
Precision linear motion solution combining cylinder and guide mechanism, featuring integrated ball bearing guides for minimal friction and anti-rotation stability. The dual piston design ensures smooth movement with 0.01mm guide rail clearance control. Compatible with vacuum applications when paired with optional seals.
- PCB component insertion machines
- Lens module assembly in camera production
- Medical device precision positioning systems
- Automated test equipment linear stages
- Semiconductor wafer handling robots
Installation protocol:
Mount on flat surface with ≤0.05mm/m parallelism tolerance. Use M4x8 mounting screws (ISO4762) torqued to 1.2N·m. Lubricate guide rails with ISO VG32 hydraulic oil if used in high-cycle (>5M strokes) applications.
| Property | Property Value |
|---|---|
| sku | STWB25X175S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 175mm |
