Airtac STWB Slide Table Cylinder STWB25X25S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB25X25S Slide Table Cylinder Specifications
- Model: STWB25X25S
- Type: Guided slide table cylinder (double-acting)
- Bore size: 25mm
- Stroke: 25mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Rubber buffer (adjustable at both ends)
- Mounting style: Square flange mounting
- Port size: M5x0.8 (dual ports on both sides)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy cylinder tube, hardened stainless steel piston rod
- Seal material: NBR (nitrile rubber)
- Protection class: IP54
- Weight: 1.8 kg ±3%
- Dimensions (L×W×H): 125mm × 42mm × 42mm (basic length 100mm + stroke 25mm)
- Standard compliance: ISO 15552 (VDMA 24562)
- Optional accessories: Magnetic sensor slots (compatible with S-08 series sensors)
A precision-guided pneumatic slide cylinder featuring dual-axis linear motion with integrated guide rails. The STWB25X25S combines lateral load capacity (up to 15N·m moment resistance) with smooth movement accuracy (±0.05mm repeatability). Anti-rotation design ensures stable payload orientation during travel, while the hard-anodized guide surfaces provide wear resistance in continuous operation cycles.
- PCB component insertion machines
- Automated optical inspection (AOI) positioning stages
- Multi-axis material handling systems
- Pharmaceutical blister packaging equipment
- Semiconductor wafer transfer mechanisms
Installation guidelines:
For optimal performance, maintain perpendicularity within 0.2mm/m during mounting.
Lubricate with ISO VG32 hydraulic oil before initial use.
Recommend installing speed controllers (ASC-06 series) for velocity adjustment below 500mm/s.
| Property | Property Value |
|---|---|
| sku | STWB25X25S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | <25 mm> |
