This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is SAUD32X100 — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the SAUD32X100 in place of this model. The SAU replacement uses the same profile body, bore, stroke, force and SC-series mounting. It moves to the current CMSG / DMSG / EMSG sensor switches (the SU used CS1-B / DS1-B) and adds the SAUF valve-integrated option.
Airtac SUD Series Double Rod Cylinder SUD32X100
The AirTAC Airtac SUD Series Double Rod Cylinder SUD32X100 is a double-acting profile-type standard cylinder with a Ø32mm bore and 100mm stroke, 1/8" air ports and adjustable end cushioning. This model is discontinued — the drop-in replacement is the SAUD32X100, which matches its bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke100 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → SAUD32X100
About the Airtac SUD Series Double Rod Cylinder SUD32X100
The AirTAC SUD32X100 is a double-acting, double-rod profile cylinder featuring a 32mm bore and 100mm stroke. Because a rod exits both ends, the push and pull forces are equal both ways at 345N @0.5 MPa, 483N @0.7 MPa, and 621N @0.9 MPa. The extruded aluminium profile barrel is more compact than an ISO 15552 cylinder of the same bore. This SUD32X100 model is discontinued and the exact drop-in replacement is the SAUD32X100, which retains the 1/8" port, M10x1.25 rod thread, and basic/FA/LB mounting.
The dual-rod design provides anti-rotation stability and allows driving two tools simultaneously, while the rear rod acts as a sensor cam. Since this SKU lacks a magnet, it cannot take a magnetic switch. For sizing, the safe working load is roughly 207N (60% of the 345N @0.5 MPa figure), yielding a vertical lift capacity of about 18kg with a 2:1 margin. Note that air cushions only decelerate the piston near stroke end; an external rod lock is required to hold loads on air loss.
Airtac SUD Series Double Rod Cylinder SUD32X100 Technical Specifications
| Model | Airtac SUD Series Double Rod Cylinder SUD32X100 |
|---|---|
| Series | SU profile-type cylinder (discontinued) |
| Replacement | SAUD32X100 |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC SU datasheet (now discontinued). The SAUD32X100 carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The SAUD32X100 produces the same force from the same bore — a true drop-in on output. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SUD Series Double Rod Cylinder SUD32X100
| SU | Profile-type standard cylinder (discontinued). |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SU-family variants: SUD (double rod), SUJ (adjustable stroke) — each maps to its SAU equivalent (SUD→SAUD, SUJ→SAUJ). The current SAU line adds the SAUF valve-integrated option.
Where the Airtac SUD Series Double Rod Cylinder SUD32X100 Is Used
Dual-Tool Driving
Simultaneously actuates two opposing tool heads with equal force both ways, maintaining strict synchronization without requiring a separate cylinder.
Anti-Rotation Guiding
The dual-rod geometry prevents piston rotation during travel, making it ideal for lifting or positioning flat panels that cannot twist.
Compact Transfer Pusher
Fits into tight machinery profiles to push parts between conveyor lanes, using the shorter profile barrel to save valuable footprint.
Replacing the Airtac SUD Series Double Rod Cylinder SUD32X100 with the SAUD32X100
To replace the discontinued SUD32X100, select the drop-in SAUD32X100, which matches the 32mm bore, 100mm stroke, 1/8" port, and FA/LB mounting. If upgrading sensing, the SAUD uses current CMSG/DMSG/EMSG sensors instead of the legacy CS1-B/DS1-B switches. Because force is equal both ways, size both directions by checking neighbour bores; the 40mm bore offers higher force, while smaller bores save space. A double rod is right when you need anti-rotation resistance or must drive two tools. For strokes >=300mm, verify side-load limits to prevent guide wear. Remember, cushions only decelerate; use an external rod lock for load holding.
Replacement checklist
- ✓ Same bore / stroke → SAUD32X100
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S): sensor family CS1-B → CMSG
- ✓ Mounting reused (FA/FB/CA/CB/LB)
- ✓ Need a built-in valve? → SAUF
Airtac SUD Series Double Rod Cylinder SUD32X100 FAQ
Yes, the SUD32X100 is discontinued. The exact drop-in replacement is the SAUD32X100, which keeps the same 32mm bore, 100mm stroke, equal-both-ways force, 1/8" port, and FA/LB mounting. The SAUD also supports the SAUF built-in-valve variant and uses current CMSG/DMSG/EMSG sensors instead of the legacy CS1-B/DS1-B.
Because it is a double-rod cylinder, force is equal both ways: 345N @0.5 MPa, 483N @0.7 MPa, and 621N @0.9 MPa. The air port is 1/8" PT thread, the rod is Ø12mm with an M10x1.25 thread, and speed ranges from 30-800 mm/s. The safe working load is approximately 207N.
