This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is SAUD32X200 — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the SAUD32X200 in place of this model. The SAU replacement uses the same profile body, bore, stroke, force and SC-series mounting. It moves to the current CMSG / DMSG / EMSG sensor switches (the SU used CS1-B / DS1-B) and adds the SAUF valve-integrated option.
Airtac SUD Series Double Rod Cylinder SUD32X200
The AirTAC Airtac SUD Series Double Rod Cylinder SUD32X200 is a double-acting profile-type standard cylinder with a Ø32mm bore and 200mm stroke, 1/8" air ports and adjustable end cushioning. This model is discontinued — the drop-in replacement is the SAUD32X200, which matches its bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke200 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → SAUD32X200
About the Airtac SUD Series Double Rod Cylinder SUD32X200
The AirTAC SUD32X200 is a discontinued double-acting double-rod profile cylinder. A rod exits both ends, meaning push and pull forces are equal at 345 N @0.5 MPa, 483 N @0.7 MPa, and 621 N @0.9 MPa. It features a 32 mm bore, 200 mm stroke, 1/8" port, and M10x1.25 rod thread. The exact drop-in replacement is the SAUD32X200, matching the body, bore, stroke, force, and FA/LB mounting.
This design prevents rod rotation and can drive two tools simultaneously. The safe working load is about 207 N (60% of the 345 N @0.5 MPa figure), allowing a vertical lift of roughly 18 kg with a 2:1 margin. This SKU lacks a magnet and cannot take a sensor. The SAUD upgrade uses CMSG/DMSG/EMSG sensors instead of the legacy CS1-B/DS1-B. Air cushions only decelerate; use an external rod lock for held loads.
Airtac SUD Series Double Rod Cylinder SUD32X200 Technical Specifications
| Model | Airtac SUD Series Double Rod Cylinder SUD32X200 |
|---|---|
| Series | SU profile-type cylinder (discontinued) |
| Replacement | SAUD32X200 |
| Bore size | Ø32 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC SU datasheet (now discontinued). The SAUD32X200 carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The SAUD32X200 produces the same force from the same bore — a true drop-in on output. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SUD Series Double Rod Cylinder SUD32X200
| SU | Profile-type standard cylinder (discontinued). |
|---|---|
| 32 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SU-family variants: SUD (double rod), SUJ (adjustable stroke) — each maps to its SAU equivalent (SUD→SAUD, SUJ→SAUJ). The current SAU line adds the SAUF valve-integrated option.
Where the Airtac SUD Series Double Rod Cylinder SUD32X200 Is Used
Dual-Tool Machining
Drives two opposing tools simultaneously from one piston, utilizing the equal push and pull force to machine parts on both ends.
Anti-Rotation Transfer
Moves parts along a conveyor without rod rotation, ensuring precise alignment during pick and place operations.
Compact Profile Pressing
Performs light pressing tasks in tight spaces where the shorter profile barrel prevents interference with nearby equipment.
Replacing the Airtac SUD Series Double Rod Cylinder SUD32X200 with the SAUD32X200
To replace the SUD32X200, order the SAUD32X200 for an exact drop-in fit. When sizing both ways, verify the equal push/pull force of 345 N @0.5 MPa is sufficient, or step to the 40 mm bore (528 N @0.5 MPa) if more force is needed. Choose a double-rod cylinder when you need anti-rotation or to drive two tools. Mounting is Basic, FA, or LB only. Because this non-magnetic SKU cannot take a sensor, the SAUD upgrade uses CMSG/DMSG/EMSG sensors instead of CS1-B/DS1-B. For this 200 mm stroke, ensure side-load alignment to prevent guide wear.
Replacement checklist
- ✓ Same bore / stroke → SAUD32X200
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S): sensor family CS1-B → CMSG
- ✓ Mounting reused (FA/FB/CA/CB/LB)
- ✓ Need a built-in valve? → SAUF
Airtac SUD Series Double Rod Cylinder SUD32X200 FAQ
Yes, the SUD32X200 is discontinued. The exact drop-in replacement is the SAUD32X200, which matches the 32 mm bore, 200 mm stroke, 1/8" port, and FA/LB mounting.
The double-rod design provides equal force both ways: 345 N @0.5 MPa, 483 N @0.7 MPa, and 621 N @0.9 MPa. The air port is 1/8" and the rod thread is M10x1.25.
