Airtac TACED Guided Compact Cylinder TACED100X10
$163.27
Regular price
$170.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TACED100X10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 21287 standard for universal mounting dimensions;
2. Threaded connection between cylinder barrel and end covers ensures high structural integrity and ease of maintenance;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Patented asymmetric bidirectional sealing configuration on piston combines compact dimensions with integrated oil reservoir function;
5. Space-saving design achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Three-sided sensor slots on the barrel facilitate seamless sensor integration;
7. Integrated shock-absorbing pads effectively dissipate residual energy from high-speed operation and mechanical rotation;
8. Comprehensive selection of mounting accessories available in multiple configurations.
Category: Guided Cylinders , Brand: AirTAC , Series: TACED
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Lubricate guide rails with ISO VG32 hydraulic oil during initial setup.
For vertical installations exceeding 45° angle, use optional spring brake module (TACED-ASB kit).
2. Threaded connection between cylinder barrel and end covers ensures high structural integrity and ease of maintenance;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Patented asymmetric bidirectional sealing configuration on piston combines compact dimensions with integrated oil reservoir function;
5. Space-saving design achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Three-sided sensor slots on the barrel facilitate seamless sensor integration;
7. Integrated shock-absorbing pads effectively dissipate residual energy from high-speed operation and mechanical rotation;
8. Comprehensive selection of mounting accessories available in multiple configurations.
Category: Guided Cylinders , Brand: AirTAC , Series: TACED
AirTAC TACED100X10 Guided Rod Compact Cylinder Specifications
- Model: TACED100X10
- Type: Double-acting guided rod cylinder
- Bore size: 100mm
- Stroke: 10mm (customizable 5-100mm)
- Rod type: Hard chrome-plated steel with precision linear guide
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G3/8 (NPT1/4 optional)
- Mounting: Standard flange (MF1) with multiple mounting hole patterns
- Temperature range: -20℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR/PU combination
- Protection rating: IP54 (standard), IP67 optional
- Max thrust: 785N @ 0.63MPa
- Weight: 2.8kg ±3% (excluding accessories)
- Dimensions:
- Main body: 150mm(L) × 112mm(W) × 100mm(H)
- Guide section: 22mm × 22mm square rail
- Total extended length: 160mm (at full stroke)
High-precision guided cylinder combining pneumatic actuation with mechanical guidance, featuring zero rotational tolerance (±0.05° angular deviation). The dual guide rod design ensures exceptional lateral load capacity (up to 500N) while maintaining smooth operation. Integrated wear indicators and grease fittings allow predictive maintenance. Requires ISO 8573-1:2010 Class 3 compressed air.
Industrial Applications:
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms for packaging lines
- Palletizing robot end-effector positioning
- Semiconductor wafer handling systems
- Die-casting machine core-pulling units
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Lubricate guide rails with ISO VG32 hydraulic oil during initial setup.
For vertical installations exceeding 45° angle, use optional spring brake module (TACED-ASB kit).
Performance Data:
- Cycle life: 5,000km travel distance (L10 rating)
- Max speed: 500mm/s (with cushion engaged)
- Repeat positioning accuracy: ±0.1mm
- Startup friction: ≤15N @ 0.5MPa
| Property | Property Value |
|---|---|
| sku | TACED100X10 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
