Airtac TACED Guided Compact Cylinder TACED100X10S
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X10S is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X10S
Double acting and double rod, the TACED100X10S pushes a rod out of both covers, so its 100 mm bore delivers an identical 3769.9 N at 0.5 MPa in each direction - there is no weaker pull side. Twin guide rods on the yoke stop the tooling rotating and carry side load, and the 10 mm stroke suits short clamp-and-release moves. The -S code on this model means the magnet is fitted, so CMSE / DMSE reed or solid-state switches can be mounted anywhere along the body slots.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which matters in a 100 mm bore class where space is usually tight. A hard-anodized aluminium barrel carries an S45C hard-chrome-plated rod, fixed TPU bumpers absorb end-of-stroke shock at both ends, and the 1/4" ports feed 0.15-1.0 MPa (22-145 psi) air filtered to 40 um. As a planning figure, treat roughly 2260 N (about 230 kgf) as the usable force at 0.5 MPa, and halve the 384 kgf vertical-lift equivalent to about 192 kg for a 2:1 margin.
Airtac TACED Guided Compact Cylinder TACED100X10S Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X10S |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X10S
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X10S Is Used
Press-fit clamping of gearbox housings
A 10 mm stroke is enough to seat or release a fixture clamp, and 3769.9 N at 0.5 MPa both ways lets the same cylinder clamp or retract a heavy housing without a larger bore.
Vertical lift assist on pallet stations
The twin guide yoke keeps a lifting plate square under load; with a 2:1 margin the bore 100 double rod lifts about 192 kg vertically at 0.5 MPa.
Position-checked gate on a packaging line
Because the -S magnet is fitted, CMSE or DMSE switches confirm gate open and closed positions, and the short body fits inside tight machine guarding.
Is the Airtac TACED Guided Compact Cylinder TACED100X10S the Right Cylinder?
At 100 mm bore this is the top of the TACED range: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, equal in both directions because a rod exits each cover. If your load needs under 1458 N at 0.5 MPa, the 63 mm bore does the same job in a smaller package. The 10 mm stroke is well inside the standard range for this bore, so no made-to-order stroke is needed. Remember the piston drifts if air is lost - add a rod lock or pilot check valve for a held load. FB flange mounting is available, and this model already carries the optional -S magnet for CMSE / DMSE switches.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X10S FAQ
Yes - the double-rod design puts a rod through both covers, so both sides see the rod-side area. Output is 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in either direction, with a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), speed 30-500 mm/s, temperature -20 to +70 C on air filtered to 40 um.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so a 100 mm bore fits where a full-length cylinder will not. This model carries the optional -S magnet, so CMSE / DMSE reed or solid-state switches can be clipped into the body slots for end-of-stroke or mid-stroke detection. A fixed TPU bumper at each end absorbs end-of-stroke energy, and FB flange mounting is available.
