Airtac TACED Guided Compact Cylinder TACED100X15
$164.93
Regular price
$172.43
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TACED100X15
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 21287 standard for universal mounting dimensions;
2. Threaded connection between cylinder barrel and end covers ensures high structural integrity and ease of maintenance;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Patented asymmetric bidirectional sealing configuration on piston combines compact dimensions with integrated oil reservoir function;
5. Space-saving design achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Three-sided sensor slots on the barrel facilitate seamless sensor integration;
7. Integrated shock-absorbing pads effectively dissipate residual energy from high-speed operation and mechanical rotation;
8. Comprehensive selection of mounting accessories available in multiple configurations.
Category: Guided Cylinders , Brand: AirTAC , Series: TACED
Installation tips:
2. Threaded connection between cylinder barrel and end covers ensures high structural integrity and ease of maintenance;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Patented asymmetric bidirectional sealing configuration on piston combines compact dimensions with integrated oil reservoir function;
5. Space-saving design achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Three-sided sensor slots on the barrel facilitate seamless sensor integration;
7. Integrated shock-absorbing pads effectively dissipate residual energy from high-speed operation and mechanical rotation;
8. Comprehensive selection of mounting accessories available in multiple configurations.
Category: Guided Cylinders , Brand: AirTAC , Series: TACED
AirTAC TACED100X15 Guided Rod Compact Cylinder Specifications
- Model: TACED100X15
- Type: Guided rod compact cylinder (double-acting)
- Bore size: 100mm
- Stroke: 15mm (Customizable 10-300mm)
- Operating pressure: 0.1–0.9 MPa
- Guide rod diameter: 20mm (Double-rod design)
- Piston rod material: SCM435 chromium-molybdenum steel
- Guide rod treatment: Hard chrome plated (5-8μm thickness)
- Cushioning type: Adjustable rubber buffer
- Mounting types: Front flange (MF1), rear flange (MF2), or foot mounting
- Seal material: NBR/PU combination
- Temperature range: -20℃ to 80℃
- Port size: G1/8 (BSPP thread)
- Weight: 8.2kg (Excluding accessories)
- Dimensions: 330mm(L) × 120mm(W) × 100mm(H) (Stroke included)
- Max lateral load: 980N
- Protection rating: IP54 (Standard), IP67 optional
- Lubrication: Pre-lubricated (Use ISO VG32 hydraulic oil if re-lubrication needed)
High-precision guided cylinder featuring integrated linear guides that eliminate rotational movement, providing exceptional lateral load capacity. The hardened steel guide rods with preloaded ball bearings ensure smooth linear motion and precise positioning accuracy (±0.1mm repeatability). Ideal for applications requiring both pushing force and precise alignment.
Typical Applications:
- Precision clamping in CNC fixture systems
- Vertical lifting mechanisms in assembly robots
- Press-fit operations in electronic component manufacturing
- Positioning stages in optical inspection equipment
- Gate control in high-speed packaging lines
Installation tips:
- Align guide rods within 0.2mm parallel tolerance during mounting
- Apply anti-seize compound on guide rod threads for saltwater environments
- For vertical mounting, install locking nuts on both guide rod ends
- Re-torque mounting bolts after 50 operating hours (18-20N·m for M10 bolts)
| Property | Property Value |
|---|---|
| sku | TACED100X15 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 100mm |
| Stroke | <15mm> |
