Airtac TACED Guided Compact Cylinder TACED100X15S
$168.39
Regular price
$175.89
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TACED100X15S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 21287 standard for universal mounting dimensions;
2. Threaded connection between cylinder barrel and end covers ensures high structural integrity and ease of maintenance;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Patented asymmetric bidirectional sealing configuration on piston combines compact dimensions with integrated oil reservoir function;
5. Space-saving design achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Three-sided sensor slots on the barrel facilitate seamless sensor integration;
7. Integrated shock-absorbing pads effectively dissipate residual energy from high-speed operation and mechanical rotation;
8. Comprehensive selection of mounting accessories available in multiple configurations.
Category: Guided Cylinders , Brand: AirTAC , Series: TACED
Installation note:
Maintain parallel alignment between guide rods and load direction.
Lubricate guide rods weekly with ISO VG32 hydraulic oil.
Avoid side impact during operation - maximum allowable misalignment: 0.5°.
2. Threaded connection between cylinder barrel and end covers ensures high structural integrity and ease of maintenance;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Patented asymmetric bidirectional sealing configuration on piston combines compact dimensions with integrated oil reservoir function;
5. Space-saving design achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Three-sided sensor slots on the barrel facilitate seamless sensor integration;
7. Integrated shock-absorbing pads effectively dissipate residual energy from high-speed operation and mechanical rotation;
8. Comprehensive selection of mounting accessories available in multiple configurations.
Category: Guided Cylinders , Brand: AirTAC , Series: TACED
AirTAC TACED100X15S Guided Rod Compact Cylinder Specifications
- Model: TACED100X15S
- Type: Guided rod compact cylinder (double-acting)
- Bore size: Ø100 mm
- Stroke: 15 mm (customizable up to 300 mm)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Guide rod type: Precision ground steel with chromium plating
- Mounting style: Front flange with mounting holes (MF1 pattern)
- Port size: G1/2 (NPT1/2 optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: SUS304 stainless steel
- Seal type: NBR wear-resistant seals
- Temperature range: -10℃ to 80℃
- Weight: 5.8 kg (typical)
- Dimensions: 230mm(L) × 128mm(W) × 128mm(H) (at mid-stroke)
- Load capacity: 1200N radial / 900N lateral (max)
- Repeat positioning accuracy: ±0.1mm
- Protection rating: IP54 (standard), IP67 optional
High-precision guided cylinder combining linear motion and anti-rotation functions. Features dual guide rods for exceptional moment resistance and minimal deflection. Integrated shock absorbers reduce end-impact noise to ≤70dB. Optional magnetic piston version (TACED100X15S-M) for position sensing.
Typical Applications:
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms in packaging machinery
- Component positioning in semiconductor handling systems
- Clamping fixtures for CNC machining centers
- Material transfer units in automated warehouses
Installation note:
Maintain parallel alignment between guide rods and load direction.
Lubricate guide rods weekly with ISO VG32 hydraulic oil.
Avoid side impact during operation - maximum allowable misalignment: 0.5°.
| Property | Property Value |
|---|---|
| sku | TACED100X15S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 100mm |
| Stroke | <15mm> |
