Description
1. Complies with ISO 21287 standard for universal mounting dimensions;
2. Threaded connection between cylinder barrel and end covers ensures high structural integrity and ease of maintenance;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Patented asymmetric bidirectional sealing configuration on piston combines compact dimensions with integrated oil reservoir function;
5. Space-saving design achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Three-sided sensor slots on the barrel facilitate seamless sensor integration;
7. Integrated shock-absorbing pads effectively dissipate residual energy from high-speed operation and mechanical rotation;
8. Comprehensive selection of mounting accessories available in multiple configurations.
Category: Guided Cylinders , Brand: AirTAC , Series: TACED
Operation note: Requires minimal lubrication (ISO VG32 recommended).
Install with ±0.2mm alignment tolerance between guide rails and mating surface.
Avoid continuous side loading >30% of rated capacity for extended lifespan.
2. Threaded connection between cylinder barrel and end covers ensures high structural integrity and ease of maintenance;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Patented asymmetric bidirectional sealing configuration on piston combines compact dimensions with integrated oil reservoir function;
5. Space-saving design achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Three-sided sensor slots on the barrel facilitate seamless sensor integration;
7. Integrated shock-absorbing pads effectively dissipate residual energy from high-speed operation and mechanical rotation;
8. Comprehensive selection of mounting accessories available in multiple configurations.
Category: Guided Cylinders , Brand: AirTAC , Series: TACED
AirTAC TACED100X25 Guided Rod Compact Cylinder Specifications
- Model: TACED100X25
- Type: Double-acting guided rod cylinder
- Bore size: 100mm
- Stroke: 25mm
- Operating pressure: 0.1-0.9 MPa
- Port size: G1/8 (NPT1/8 optional)
- Cushioning: Adjustable rubber bumper (both ends)
- Rod type: Hard chrome-plated steel with integrated guide rails
- Seal material: NBR/PU hybrid seals
- Temperature range: -10℃ to 80℃
- Weight: 3.8kg ±2%
- Dimensions: 230mm(L) × 130mm(W) × 130mm(H)
- Guide mechanism: Dual linear ball bearings (precision grade P4)
- Lateral load capacity: ≤500N
- Repeat positioning accuracy: ±0.05mm
- Protection rating: IP54 (standard), IP67 optional
High-precision guided cylinder combining pneumatic actuation with mechanical guidance, engineered for applications requiring exceptional anti-rotation stability. The integrated dual linear bearings and hardened guide rails enable smooth operation under heavy moment loads. Features wear-compensating seals and oil-free operation capability.
Typical Applications:
- Precision alignment in automated assembly lines
- Vertical lifting mechanisms in packaging machinery
- Positioning fixtures for CNC machine tooling
- Material handling systems with side-load requirements
- Semiconductor wafer transfer equipment
Operation note: Requires minimal lubrication (ISO VG32 recommended).
Install with ±0.2mm alignment tolerance between guide rails and mating surface.
Avoid continuous side loading >30% of rated capacity for extended lifespan.
Special configuration:
Allow 15mm clearance around guide rails for thermal expansion.
Use M8x1.25 mounting bolts (grade 8.8 or higher) with 20N·m torque specification.
Break-in period: 500 cycles at 50% rated pressure recommended.
| Property | Property Value |
|---|---|
| sku | TACED100X25 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 100mm |
| Stroke | <25 mm> |
