Airtac TACED Guided Compact Cylinder TACED100X25S
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X25S is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 25mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke25 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X25S
A double acting, double-rod compact cylinder built to ISO 21287, the TACED100X25S pushes a 100 mm bore through a 25 mm stroke with a rod leaving both covers. Because both chambers see the rod-side area, output force is identical in each direction: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa. Twin guide rods on the yoke stop the tooling rotating and carry side load, so a heavy press plate or clamping beam stays square without an external guide. The -S code on this model means the magnet is fitted, so CMSE / DMSE reed or solid-state switches can be mounted anywhere along the body slots.
The hard-anodized aluminium body with a roller-burnished bore pairs with an S45C hard-chrome plated 20 mm rod, and a fixed TPU bumper at each end absorbs end-of-stroke shock. Running on 0.15-1.0 MPa (22-145 psi) air filtered to 40 um at 30-500 mm/s, the short body saves about 50% of the mounting length of an ISO 15552 profile cylinder. For planning, treat roughly 2262 N (about 230 kg of push) as the usable working force at 0.5 MPa, and with a 2:1 margin this cylinder lifts about 192 kg vertically.
Airtac TACED Guided Compact Cylinder TACED100X25S Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X25S |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 25 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X25S
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×25 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X25S Is Used
Heavy fixture clamping
The 3769.9 N through-rod force clamps large machined castings in a CNC fixture from either side, with the twin guide yoke keeping the clamp shoe square to the part.
Press-fit assist station
A 25 mm stroke suits short press or stake operations on bearing bushes and dowels, where about 230 kg of usable push at 0.5 MPa does the work without a full-size press.
Palletizer part pusher
Equal force in both directions lets one cylinder push palletized cartons off a conveyor on the forward stroke and retract the pusher plate squarely on the return, tracked by CMSE switches.
Is the Airtac TACED Guided Compact Cylinder TACED100X25S the Right Cylinder?
At 3769.9 N per direction at 0.5 MPa, the 100 mm bore sits at the top of the TACED range; step down to the 80 mm bore (2356.2 N) for lighter clamps or up from the 63 mm bore (1458.1 N) when force runs short. The 25 mm stroke is well inside the standard range for this bore, so no made-to-order build is needed. Air ports are 1/4" and the rod end carries a female M12x1.75 thread. Remember the piston drifts if air is lost, so add a rod lock or pilot check valve where a load must stay held. FB flange, CA, CB, CR and FTC mountings are available, and the fitted -S magnet lets CMSE / DMSE switches report end positions.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X25S FAQ
Yes. As a double-rod cylinder, the rod-side area works in both directions, so output is equal each way: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, with a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s, and the 20 mm rod ends in a female M12x1.75 thread with 1/4" air ports.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it fits tight gantries and guarding. The -S code means the magnet is fitted, so CMSE / DMSE reed or solid-state switches can be slid into the body slots for end-of-stroke signalling. A fixed TPU bumper at each end absorbs end-of-stroke energy, and FB flange or CA, CB, CR, FTC mountings are available.
