Airtac TACED Guided Compact Cylinder TACED100X35S
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X35S is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 35mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke35 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X35S
Double acting and double rod, the TACED100X35S pushes a 100 mm bore through a 35 mm stroke with a rod leaving both covers, so the force is identical in each direction: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa. Twin guide rods on a yoke stop the tooling rotating and carry side load, so a heavy press plate or clamp arm stays square without a separate linear guide. The -S code on this model means the magnet is fitted, and CMSE or DMSE reed and solid-state switches can be mounted anywhere along the body slots.
The hard-anodized aluminium body with a roller-burnished bore and an S45C hard-chrome plated 20 mm rod shrugs off wear in high-cycle plants, and a fixed TPU bumper at each end absorbs end-of-stroke shock. This ISO 21287 compact body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which matters when a 35 mm stroke must fit inside a guarded weld cell or a deep draw die. At 0.5 MPa, plan on roughly 2262 N (about 230 kgf) of usable work, and the rod will lift about 192 kg vertically with a 2:1 margin.
Airtac TACED Guided Compact Cylinder TACED100X35S Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X35S |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 35 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X35S
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×35 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X35S Is Used
Stamping die ejection
The 3769.9 N both-ways force ejects formed sheet parts from a draw die, and the non-rotating yoke keeps the ejector plate flat against the die face.
Weld cell clamp arm
A 35 mm stroke clamps brackets inside a tight robot weld fixture, with the compact body saving about 50% of the length of an ISO 15552 profile cylinder.
Pallet press-down station
Presses cartons or totes down on a packaging line at up to 500 mm/s, lifting about 192 kg vertically with a 2:1 safety margin at 0.5 MPa.
Is the Airtac TACED Guided Compact Cylinder TACED100X35S the Right Cylinder?
At 100 mm bore this is the top of the TACED range: 3769.9 N per direction at 0.5 MPa. If your load needs under 1458 N at 0.5 MPa, the 63 mm bore does the same job smaller; if you need more, nothing in the series exceeds this bore, so consider parallel units. The 35 mm stroke sits well inside the 300 mm maximum standard stroke for this bore, so it is a catalogue item, not a made-to-order build.
Ports are 1/4" (PT thread) and the rod end carries a female M12x1.75 thread. Remember the piston drifts when air is lost, so pair it with a rod lock or pilot check valve if a die or fixture must stay held. FB flange mounting suits fixed press heads; order CMSE or DMSE switches alongside this -S model for end-of-stroke sensing.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X35S FAQ
Yes. Because a rod exits both covers, both sides work on the rod-side area, so output is equal each way: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, with a maximum of 768.8 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), speed 30-500 mm/s, and the twin guide yoke keeps the load non-rotating throughout.
The ISO 21287 aluminium body is about 50% shorter in mounting length than an ISO 15552 profile cylinder, so it slots into shallow fixtures and guarded machines. The S in TACED100X35S means the optional magnet is fitted, letting CMSE or DMSE reed or solid-state switches sense position along the body slots; without the -S code there would be no magnet. A fixed TPU bumper at each end absorbs end-of-stroke impact.
