Airtac TACED Guided Compact Cylinder TACED100X40
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X40 is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 40mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke40 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X40
A double acting, double-rod ISO 21287 compact cylinder, the TACED100X40 pushes a rod out of both covers, so the 100 mm bore delivers the same 3769.9 N at 0.5 MPa in either direction (5277.9 N at 0.7 MPa, up to 768.8 kgf at 1.0 MPa). Twin guide rods on the yoke stop the tooling rotating and carry side load, keeping a press plate or gripper square without an external guide. The hard-anodized aluminium body with an S45C hard-chrome plated 20 mm rod runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), 30-500 mm/s.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so this 100 mm bore fits deep press dies and heavy clamping fixtures where a full-length cylinder will not reach. For sizing: the 0.5 MPa force works out to roughly 2262 N of usable work, and halving the 384 kgf equivalent gives a vertical lift of about 192 kg with a 2:1 margin. A fixed TPU bumper sits at both ends, and the optional -S magnet enables CMSE / DMSE switches.
Airtac TACED Guided Compact Cylinder TACED100X40 Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X40 |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 40 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X40
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×40 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X40 Is Used
Press die clamping
The 3769.9 N equal push and pull clamps and releases heavy stamping dies inside a press bolster, with the twin guide yoke keeping the clamp plate square.
Pallet lift-and-lower station
About 192 kg vertical lift with a 2:1 margin handles loaded pallet plates on an assembly line, and the same force lowers them under control.
CNC fixture toggle actuation
Short 40 mm stroke throws a toggle clamp on a machining fixture, and the compact body saves about 50% of the length of an ISO 15552 profile cylinder inside the fixture base.
Is the Airtac TACED Guided Compact Cylinder TACED100X40 the Right Cylinder?
At 3769.9 N per side at 0.5 MPa, this bore sits near the top of the ACE range; step down to TACED63 (1458.1 N) for lighter clamps or stay here for heavy die work. If you need more, confirm from datasheet, as 100 mm is the largest bore listed. Stroke 40 mm is within the 300 mm standard range for bore 100. Remember the piston drifts when air is lost - add a rod lock or pilot check valve if the load must be held. Mounting is FB flange, the rod end is female M12x1.75, and the optional -S magnet is required for CMSE / DMSE switch position feedback.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X40 FAQ
Yes - the double rod means both sides see the rod-side area, so output is equal both ways: 3769.9 N at 0.5 MPa, 5277.9 N at 0.7 MPa, and a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi) with 1.5 MPa (215 psi) proof pressure, speed 30-500 mm/s, air filtered to 40 um, -20 to +70 C.
It is an ISO 21287 compact cylinder, roughly 50% shorter in mounting length than an ISO 15552 profile cylinder, with a hard-anodized aluminium body and fixed TPU bumpers at both ends. The magnet is the optional -S code - without it no CMSE or DMSE switch can be fitted. The 100 mm bore uses a 1/4" port, the rod end is female M12x1.75, and FB flange mounting is available.
