Airtac TACED Guided Compact Cylinder TACED100X45
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X45 is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 45mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke45 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X45
A double acting, double rod compact cylinder built to ISO 21287, the TACED100X45 pushes a 100 mm bore through a 45 mm stroke with a rod leaving both covers. Because each side works on the rod-side area, output is a matched 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in extend and retract alike. Twin guide rods on the yoke stop the tooling rotating and carry side load, so a gripper or press plate stays square without an external guide.
The hard-anodized aluminium body with an S45C hard-chrome plated 20 mm rod shrugs off wear in daily production, and the short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, letting it slot into dense weld fixtures and gantries. As a rule of thumb, plan on roughly 2260 N of usable work at 0.5 MPa, and for vertical duty halve the 384 kg thrust equivalent to lift about 192 kg with margin. A fixed TPU bumper at each end absorbs end-of-stroke shock, and the optional -S magnet enables CMSE / DMSE switches.
Airtac TACED Guided Compact Cylinder TACED100X45 Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X45 |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 45 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X45
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×45 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X45 Is Used
Weld fixture clamping
The matched 3769.9 N clamp and unclamp force clamps and releases car-body panels with identical pressure, while the twin guide yoke keeps the clamp shoe square to the nest.
Press-fit staking station
A 45 mm stroke covers bearing or bushing staking in electronics assembly; about 2260 N of practical force at 0.5 MPa seats parts without overshooting the frame.
Palletizer push-off arm
Equal force both ways sweeps cartons off a conveyor in either direction, and the short ISO 21287 body fits the tight header space above the belt.
Is the Airtac TACED Guided Compact Cylinder TACED100X45 the Right Cylinder?
At 3769.9 N per direction this is the top of the ACE compact range; step down to the TACED80 (2356.2 N at 0.5 MPa) for lighter clamps or stay here for heavy press and lift tooling. Remember the piston drifts if air is lost, so add a rod lock or pilot check valve where a load must stay put. The 45 mm stroke is within the 300 mm standard limit for bore 100, air is supplied through a 1/4" port, the rod end carries a female M12x1.75 thread, and FB flange mounting plus the optional -S magnet (for CMSE / DMSE switches) can be ordered to suit the machine.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X45 FAQ
Yes - the double rod design means a rod exits both covers, so extend and retract both act on the rod-side area. Output is 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in either direction, equal both ways, with a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), and speed 30-500 mm/s.
The ISO 21287 compact body is hard-anodized aluminium with a hard-chrome plated S45C rod, and it saves about 50% of the mounting length of an ISO 15552 profile cylinder. A fixed TPU bumper at each end absorbs end-of-stroke energy. Sensing needs the optional -S magnet code - without it no magnet is fitted and no CMSE / DMSE switch can be mounted. The piston does not hold position when air is lost, so use a rod lock or pilot check valve for held loads.
