Airtac TACED Guided Compact Cylinder TACED100X45S
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X45S is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 45mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke45 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X45S
This is a double acting, double rod AirTAC TACED100X45S: an ISO 21287 compact cylinder with a 100 mm bore and 45 mm stroke, built on a hard-anodized aluminium body with an S45C hard-chrome plated 20 mm rod. A rod exits BOTH covers, so output force is EQUAL in both directions - 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa either way, peaking at 768.8 kgf at 1.0 MPa. Twin guide rods on a yoke stop the tooling rotating and carry side load, so a heavy press plate or clamping beam stays square without an external guide.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which is why it drops into tight press fixtures and gantry frames a full-length cylinder cannot fit. For planning, treat roughly 2262 N (0.6 of the 0.5 MPa rating) as the usable working force - enough to lift about 192 kg vertically with a 2:1 margin. This -S model carries the optional magnet, so CMSE / DMSE switches can be mounted for end-of-stroke sensing; a fixed TPU bumper at both ends absorbs end-of-stroke energy. Operating range is 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s, with 1/4" ports and an M12x1.75 female rod thread.
Airtac TACED Guided Compact Cylinder TACED100X45S Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X45S |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 45 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X45S
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×45 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X45S Is Used
Press-fit stamping fixture
With 3769.9 N at 0.5 MPa in both directions, the TACED100X45S presses bearings into housings on a short 45 mm stroke, and the twin guide yoke keeps the punch square without extra guiding.
Gantry pick-and-place head
The compact body - about 50% shorter than an ISO 15552 profile cylinder - fits inside a low gantry crossbeam, while equal force both ways lets the head clamp and release a 190 kg casting with the same rating.
Indexing table push-pull station
A rod exits both covers, so the same 5277.9 N at 0.7 MPa indexes a rotary table forward and back, and CMSE switches on the -S magnet confirm each 45 mm index position.
Is the Airtac TACED Guided Compact Cylinder TACED100X45S the Right Cylinder?
At 100 mm bore this is the top of the TACED range - 3769.9 N both ways at 0.5 MPa. Step down to the 80 mm bore (2356.2 N) if the load is lighter, or move to a tandem arrangement if you need more than 5277.9 N at 0.7 MPa. The 45 mm stroke sits well inside the 300 mm max standard stroke for this bore, so it is a catalog item, not a made-to-order build.
Remember the piston drifts if air is lost - it never locks or holds a load, so add a rod lock or pilot check valve where a held position matters. FB flange mounting suits fixed press tooling, and the -S magnet on this model lets CMSE / DMSE switches report both rod ends. Confirm exact envelope dimensions from the datasheet before designing the fixture.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X45S FAQ
Yes - it is a double rod cylinder, so a 20 mm rod exits both covers and both sides see the rod-side area. Output is 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, identical pushing and pulling, with a maximum of 768.8 kgf at 1.0 MPa. In practice plan on about 2262 N of real working force at 0.5 MPa, roughly a 192 kg vertical lift with a 2:1 margin.
It is an ISO 21287 compact cylinder: hard-anodized aluminium body, S45C hard-chrome rod, threaded aluminium covers and a fixed TPU bumper at each end that decelerates the piston at stroke ends. The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder. The -S code means the magnet is fitted, so CMSE / DMSE reed or solid-state switches can be mounted on the body slots; ports are 1/4" PT and the rod end carries an M12x1.75 female thread.
