Airtac TACED Guided Compact Cylinder TACED100X5
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X5 is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 5mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke5 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X5
This is a double acting, double rod compact cylinder built to ISO 21287: a 20 mm rod exits BOTH covers of the hard-anodized aluminium body, so the 100 mm bore delivers 3769.9 N at 0.5 MPa in EACH direction - the same rod-side area works both ways. Twin guide rods on the yoke stop the tooling rotating and carry side load, keeping a press plate or clamp square without an external guide. The 5 mm stroke suits short-throw clamping and ejection steps.
At 0.7 MPa the output rises to 5277.9 N either way, with a peak of 768.8 kgf at 1.0 MPa. Because only about 60% of the rated force should be spent on real work, plan on roughly 2262 N - enough to lift about 192 kg vertically with a 2:1 margin. The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into tight press fixtures where a full-length body will not. Air supply is filtered to 40 um, pressure runs 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s, and a fixed TPU bumper absorbs end-of-stroke shock at both ends.
Airtac TACED Guided Compact Cylinder TACED100X5 Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X5 |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 5 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X5
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×5 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X5 Is Used
Short-stroke press fitting
The 5 mm throw and 3769.9 N both-ways force seat bearings or bushings in a compact press fixture, with the twin guide yoke keeping the punch square.
Heavy clamp on a machining fixture
Equal 5277.9 N clamping either way at 0.7 MPa locks a cast housing against a jig stop; the short body fits inside the fixture envelope.
Ejector on a packaging line
A 5 mm kick pushes a filled carton off a conveyor stop; the through-rod gives the same push force whichever side is plumbed.
Is the Airtac TACED Guided Compact Cylinder TACED100X5 the Right Cylinder?
At 3769.9 N per direction at 0.5 MPa, the 100 mm bore is the top of the TACED range - step down to TACED80X5 (2356.2 N) for lighter press-fit work or up from TACED63X5 (1458.1 N) when a heavier clamp is needed. Note it does not hold position if air is lost; add a rod lock or pilot check valve for a held load. Rod end is a female M12x1.25 thread with a 1/4" PT port; FB flange mounting is available. This version has no magnet - order the optional -S code if you need CMSE / DMSE switch sensing.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X5 FAQ
Yes - it is a double rod cylinder, so a 20 mm rod exits both covers and both sides see the rod-side area. Output is 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in EITHER direction, peaking at 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, temperature -20 to +70 C.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it fits tight guards and fixtures. A fixed TPU bumper at each end absorbs end-of-stroke shock. Sensing needs the optional -S magnet code - this base model has no magnet, so CMSE / DMSE switches only work when -S is ordered. FB flange mounting is available.
