Airtac TACED Guided Compact Cylinder TACED100X50
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X50 is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 50mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke50 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X50
Double acting with a rod leaving both covers, the TACED100X50 delivers 3769.9 N in each direction at 0.5 MPa because both sides work on the rod-side area. The 100 mm bore sits at the top of the ACE range, and the ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so heavy clamping fits into tight press frames and weld fixtures. A twin guide yoke with two guide rods stops the tooling rotating and carries side load, keeping a press plate square without an external guide.
The hard-anodized aluminium body carries a 20 mm S45C hard-chrome rod, and a fixed TPU bumper at each end absorbs end-of-stroke shock. Plan for roughly 2262 N of real work at 0.5 MPa, which is about 230 kg of usable thrust; halving the 384 kg vertical-lift equivalent gives a 2:1 margin, so it lifts about 192 kg vertically. Speed range is 30-500 mm/s at 0.15-1.0 MPa (22-145 psi).
Airtac TACED Guided Compact Cylinder TACED100X50 Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X50 |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 50 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X50
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X50 Is Used
Press frame clamping
The 3769.9 N dual-direction thrust clamps steel housings in a 50 mm stroke press fixture, with the twin guide yoke keeping the pressure plate square.
Pallet stopper raise-lower
A 100 mm double rod lifts and lowers a conveyor stopper blade, pushing and pulling with equal 3769.9 N force at 0.5 MPa for repeatable indexing.
Weld fixture gate drive
Slides a heavy weld-fixture gate both ways at up to 500 mm/s, where the non-rotating twin rods keep the gate aligned without external guides.
Is the Airtac TACED Guided Compact Cylinder TACED100X50 the Right Cylinder?
At this force class the step down is the 80 mm bore at 2356.2 N and the step up does not exist in the range, so 100 mm is the strongest TACED offered. Both directions give the same 3769.9 N at 0.5 MPa, so sizing is the same for push and pull strokes. Remember the piston drifts if air is lost, so add a rod lock or pilot check valve where a load must stay put. The 1/4" port suits higher flow at this bore, mounting is FB flange, and order the optional -S code if you need CMSE or DMSE switch positions.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X50 FAQ
Yes. Because a rod exits both covers, both directions work on the rod-side area: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, equal push and pull. Maximum output at 1.0 MPa is 768.8 kgf. Operating pressure is 0.15-1.0 MPa (22-145 psi) and speed is 30-500 mm/s.
It is an ISO 21287 compact cylinder whose short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a hard-anodized aluminium body, M12x1.75 female rod thread and fixed TPU bumpers at both ends. Sensing needs the optional -S magnet code; with -S ordered, CMSE or DMSE switches mount in the body slots. FB flange mounting is available.
