Airtac TACED Guided Compact Cylinder TACED100X55S
2. Threaded connection between cylinder barrel and end covers ensures high structural integrity and ease of maintenance;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Patented asymmetric bidirectional sealing configuration on piston combines compact dimensions with integrated oil reservoir function;
5. Space-saving design achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Three-sided sensor slots on the barrel facilitate seamless sensor integration;
7. Integrated shock-absorbing pads effectively dissipate residual energy from high-speed operation and mechanical rotation;
8. Comprehensive selection of mounting accessories available in multiple configurations.
Category: Guided Cylinders , Brand: AirTAC , Series: TACED
AirTAC TACED100X55S Guided Rod Compact Cylinder Specifications
- Model: TACED100X55S
- Type: Guided rod double-acting compact cylinder
- Bore size: 100mm
- Stroke: 55mm
- Structure: Square body with dual guide rods
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: G3/8 (ISO standard)
- Cushion type: Adjustable buffer at both ends
- Guide rod material: Hard chrome-plated steel
- Mounting options: Front flange (MF1), rear flange (MF2), foot mounting (MF4)
- Weight: 3.5kg (without accessories)
- Dimensions: 255mm(L) × 125mm(W) × 100mm(H)
- Protection rating: IP54 (standard)
- Seal material: NBR (nitrile rubber) with wear-resistant ring
- Max lateral load capacity: 500N
- Guide rod diameter: 20mm
- Piston rod thread: M16×1.5
A precision-guided cylinder combining compact design with exceptional moment resistance. The dual hardened guide rods (20mm diameter) and square body construction ensure stable linear motion under heavy side loads. Features adjustable pneumatic cushions for smooth stroke-end deceleration and reduced impact noise. Optional magnetic piston version available for position sensing (add "-M" suffix to model).
- Precision alignment in robotic pick-and-place systems
- Vertical lifting mechanisms in packaging lines
- Clamping fixtures for CNC machining centers
- Material transfer gates in automated warehouses
- Glass panel handling equipment
Installation tip:
Ensure guide rods are parallel to mounting surface within 0.1mm/m tolerance.
Apply lithium-based grease to guide rods during maintenance intervals (every 500km travel).
Avoid welding spatter exposure - use protective covers in foundry environments.
| Property | Property Value |
|---|---|
| sku | TACED100X55S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 100mm |
| Stroke | 55mm |
