Airtac TACED Guided Compact Cylinder TACED100X5S
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X5S is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 5mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke5 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X5S
A double acting, double-rod actuator built to ISO 21287 compact dimensions, the TACED100X5S pushes a 100 mm bore through a 5 mm stroke and delivers 3769.9 N in BOTH directions at 0.5 MPa (5277.9 N at 0.7 MPa), because a rod exits each cover and both sides work on the rod-side area. Twin guide rods on the yoke stop the tooling rotating and carry side load, so a heavy press plate or clamp shoe stays square with no external guide. The hard-anodized aluminium body with S45C hard-chrome rod runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), 30-500 mm/s.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which matters when a 100 mm bore must fit inside a guarded weld fixture or a dense palletizer frame. A fixed TPU bumper at each end absorbs end-of-stroke shock, and the fitted -S magnet accepts CMSE / DMSE switches for end-position sensing. Plan for about 2262 N of real work at 0.5 MPa (roughly 0.6 of the rating); with a 2:1 margin that lifts about 115 kg vertically.
Airtac TACED Guided Compact Cylinder TACED100X5S Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X5S |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 5 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X5S
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×5 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X5S Is Used
Short-stroke stamping mark
The 5 mm stroke and 3769.9 N both-ways thrust suit a date-code dot stamp on aluminium extrusions, where the twin guide yoke keeps the die square over the part.
Weld fixture clamping
Clamps a car-body bracket against locating pins inside a tight weld cell; the compact body fits where an ISO 15552 profile cylinder would be about twice as long.
Palletizer push-off
Nudges a carton row sideways on a palletizer conveyor with equal force in either direction, and CMSE switches on the fitted magnet confirm home and extended.
Is the Airtac TACED Guided Compact Cylinder TACED100X5S the Right Cylinder?
At this force class the neighbours are 80 mm (2356.2 N at 0.5 MPa) and the top of the range is the same 100 mm bore in longer strokes up to 300 mm standard. If your job needs less than about 2300 N of usable thrust, step down to bore 80 and save air; if you need the full 3769.9 N both ways, this is the largest TACED available. Remember the piston drifts when air is lost - for a held vertical load add a rod lock or pilot check valve. FB flange mounting suits bolted fixture plates, and the -S magnet on this model pairs with CMSE / DMSE switches.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X5S FAQ
Yes - it is a double-rod cylinder, so a rod exits both covers and both directions work on the rod-side area. Output is 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, equal in both directions, with a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so a 100 mm bore fits guarded frames and tight fixtures. A fixed TPU bumper at each end absorbs end-of-stroke shock, FB flange mounting is available, and because this model carries the optional -S magnet you can fit CMSE / DMSE reed or solid-state switches for position feedback.
