Airtac TACED Guided Compact Cylinder TACED100X75S
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X75S is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 75mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke75 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X75S
Double acting with a rod leaving both covers, the TACED100X75S pushes and pulls with identical force because each side works on the rod-side area: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, equal in both directions. Twin guide rods on the yoke stop the tooling from rotating and take side load, so a heavy press plate or lifting fixture stays square with no external guide. The 100 mm bore tops the range with a maximum of 768.8 kgf at 1.0 MPa.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which matters when a 75 mm stroke must fit inside a guarded weld cell or a deep draw die. The hard-anodized aluminium body carries a hard-chrome plated S45C rod, fixed TPU bumpers sit at both ends, and the optional -S magnet this model carries lets CMSE / DMSE switches report position. Plan on roughly 2262 N of real work at 0.5 MPa, which lifts about 115 kg vertically with a 2:1 margin.
Airtac TACED Guided Compact Cylinder TACED100X75S Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X75S |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 75 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X75S
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×75 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X75S Is Used
Pallet clamp actuation
The 3769.9 N clamping force at 0.5 MPa, equal on extend and retract, seats heavy pallet clamps in a warehouse conveyor system, with the 75 mm stroke clearing the fixture for loading.
Stamping die part ejection
In a press shop the twin guide rods eject formed steel panels without the ejector plate twisting, and the short ISO 21287 body slots into the die shoe where a full-length profile cylinder cannot.
Lift-and-locate fixture
Raising about 115 kg of aluminium casting vertically with a 2:1 margin, the double-rod design lifts and lowers at the same force, while CMSE switches on the -S magnet confirm up and down positions.
Is the Airtac TACED Guided Compact Cylinder TACED100X75S the Right Cylinder?
At 3769.9 N per side at 0.5 MPa this is the largest TACED bore; if your load needs under 1458.1 N, the 63 mm version saves air and money, and the 80 mm bore at 2356.2 N covers mid-range jobs. Air supply should be filtered to 40 um at 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s. Remember the piston drifts if air is lost - add a rod lock or pilot check valve when a load must stay put. FB flange mounting suits fixed machine frames, and the -S magnet on this model pairs with CMSE / DMSE switches.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X75S FAQ
Yes - the double-rod construction means a rod exits both covers and both strokes act on the rod-side area, so output is equal either way: 3769.9 N at 0.5 MPa, 5277.9 N at 0.7 MPa, and up to 768.8 kgf at the 1.0 MPa maximum. Operating pressure is 0.15-1.0 MPa (22-145 psi) with 1.5 MPa (215 psi) proof pressure, air filtered to 40 um, speed 30-500 mm/s, temperature -20 to +70 C.
It is an ISO 21287 compact cylinder with a hard-anodized aluminium body and threaded aluminium covers, saving about 50% of the mounting length of an ISO 15552 profile cylinder - useful in tight gantries and dies. A fixed TPU bumper at each end absorbs end-of-stroke energy. This model carries the optional -S magnet, so CMSE / DMSE reed or solid-state switches can be mounted in the body slots; the rod end is female M12x1.75 and the port is 1/4" PT.
