Airtac TSAIL Guided Cylinder TSAIL100X100S
$767.93
Regular price
$775.43
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X100S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation notes:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL100X100S Guided Cylinder with Integrated Guide Frame
- Model: TSAIL100X100S
- Type: Double-acting guided cylinder with precision linear guides
- Bore size: 100mm
- Stroke: 100mm (customizable: 50-500mm)
- Operating pressure: 0.2-1.0 MPa
- Guide mechanism: 4-row ball bearing slide block
- Piston rod material: Chrome-plated carbon steel (S45C)
- Seal material: NBR + PU combination
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable hydraulic buffer (both ends)
- Mounting style: Horizontal base mounting (optional flange kits available)
- Port size: G1/2 (BSPP thread)
- Weight: 12.8kg ±2%
- Dimensions:
- Length: 400mm (including rod)
- Width: 160mm (guide block width)
- Height: 135mm (mounting base to top)
- Lubrication: Pre-lubricated (Grease life: 3,000km travel distance)
Heavy-duty guided cylinder featuring dual-piston design and precision ground guide rails (HRC60 hardness) for moment resistance. The T-shaped guide block provides anti-rotation stability with ±0.05mm repeat positioning accuracy. Integrated shock absorbers reduce end-impact noise to <65dB. Rated for 10,000km service life at max load.
Typical Applications:
- Vertical lifting systems in automotive assembly lines
- Precision pressing operations in die-casting machines
- Material handling robots with side load requirements
- Glass panel transfer systems requiring tilt prevention
- High-moment applications in solar panel manufacturing
Installation notes:
- Align guide rails within 0.2mm/m parallel tolerance
- Apply ISO VG32 hydraulic oil if external lubrication needed
- Max side moment load: 1,960N·m | Allowable eccentricity: 15mm
| Property | Property Value |
|---|---|
| sku | TSAIL100X100S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 100mm |
| Bearing Category | Linear Bearing |
