Airtac TSAIL Guided Cylinder TSAIL100X150
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Series Guided Cylinder TSAIL100X150 Technical Details
- Model: TSAIL100X150
- Bore size: Ø100mm
- Stroke: 150mm
- Structure: Double-acting with integrated guide mechanism
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Guide type: Heavy-duty linear ball bearing system
- Rod material: Hard chrome-plated steel rod
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid seals
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (Grease-free operation)
- Mounting options: Front/rear flange with ISO/VDMA standard patterns
- Weight: Approx. 8.7kg (bare cylinder)
- Dimensions: 320mm(L) × 142mm(W) × 142mm(H) (extended length)
- Accessory ports: Two M10x1.0 pneumatic ports (G1/8 adapters included)
- Position detection: Optional magnetic sensor slots (M9 connector prep)
- Protection rating: IP54 (standard), IP67 w/optional wiper upgrade
High-precision guided cylinder engineered for multi-axis alignment stability. Features anti-rotation guidance with ±0.05mm repeat positioning accuracy. The dual-bearing guide rail system absorbs lateral forces up to 2,500N·m torque capacity, making it ideal for eccentric load applications. Requires 40μm filtered air with recommended 1-3 drops of ISO VG32 oil per m³ for optimal seal life.
- Automated palletizing systems requiring precise vertical alignment
- Die-casting machine ejector mechanisms
- Automotive welding fixture positioning
- Glass panel handling robots with lateral stability needs
- Precision press-fit assembly stations
Installation guidelines:
Mount on machined surface with flatness ≤0.1mm/m. Use M12x1.75 mounting bolts torqued to 78-98N·m.
Align guide rails within 0.2mm parallel tolerance. Perform 50-100 low-pressure break-in cycles before full operation.
| Property | Property Value |
|---|---|
| sku | TSAIL100X150 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 150mm |
| Bearing Category | Linear Bearing |
