Airtac TSAIL Guided Cylinder TSAIL100X200
$801.64
Regular price
$809.14
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X200
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation notes:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Series Guide Frame Cylinder TSAIL100X200 Specifications
- Model: TSAIL100X200
- Type: Double-acting cylinder with integrated linear guide
- Bore size: Ø100mm
- Stroke: 200mm
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s
- Cushion type: Adjustable rubber buffer (both ends)
- Guide mechanism: Heavy-duty square rail with 4 precision linear bearings
- Mounting style: Fixed base (MF1) with multiple mounting holes
- Port size: G3/8 (NPT1/2 optional)
- Material: Aluminum alloy cylinder tube, hardened steel piston rod
- Seal material: NBR/PU combination
- Temperature range: -20℃ to 80℃
- Weight: ~18.5kg (without accessories)
- Dimensions:
- Body length: 400mm (excluding rod extension)
- Guide rail width: 128mm
- Total height: 180mm (including mounting base)
- Centerline height: 50mm (from base to piston axis)
- Load capacity:
- Max moment resistance: 650 N·m
- Max lateral load: 15,000 N
- Max axial load: 30,000 N
High-precision guided cylinder engineered for heavy-duty applications requiring exceptional moment resistance and alignment stability. Features integrated recirculating ball bearing guides that eliminate rotational play, making it ideal for precision positioning tasks. The anodized aluminum construction ensures corrosion resistance in harsh environments.
Typical Applications:
- Automated palletizing systems with heavy payloads
- Press brake tool positioning in metal fabrication
- Glass handling equipment requiring vibration-free operation
- Automotive welding fixture clamping mechanisms
- Large-format CNC router Z-axis drives
Installation notes:
- Ensure guide rail alignment within 0.2mm/m using precision level
- Apply lithium soap-based grease to guide rails every 500km of travel
- Use rigid mounting surface with flatness ≤0.1mm
- Install shock absorbers when operating at >600mm/s piston speeds
| Property | Property Value |
|---|---|
| sku | TSAIL100X200 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | <200mm> |
| Bearing Category | Linear Bearing |
