Airtac TSAIL Guided Cylinder TSAIL100X200S
$807.22
Regular price
$814.72
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X200S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation guidelines:
Ensure guide rods are parallel to mounting surface within 0.2mm/m tolerance.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 50mm clearance behind cylinder for stroke extension.
Critical note:
Maximum side moment load decreases by 15% when operating at temperatures
above 60℃. Use heat-resistant seals (option code -HR) for continuous
high-temperature applications.
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL100X200S Guided Rod Cylinder Technical Details
- Series: TSAIL (Guided Cylinder Series)
- Bore size: Ø100mm
- Stroke: 200mm
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: Front flange MF1 with reinforced base
- Port size: PT1/2 (G1/2 optional)
- Guided structure: Dual stainless steel rods (Ø20mm)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel
- Seal type: Nitrile rubber (NBR) with wear-resistant ring
- Weight: 12.8kg ±2%
- Dimensions: 450mm(L) × 168mm(W) × 168mm(H)
- Max lateral load: 850N (guide rod direction)
- ISO standard: 15552 compliant
- Protection class: IP54 (standard), IP67 optional
Heavy-duty guided cylinder engineered for precision linear motion under high moment loads. Features dual hardened guide rods with linear bushings for enhanced stability, making it ideal for applications requiring anti-rotation and precise positioning. The reinforced base design minimizes deflection during side loading operations.
Typical Industrial Applications:
- Automated material handling systems
- Press machine tooling positioners
- Die-casting machine ejectors
- Automotive welding fixture clamps
- Glass manufacturing conveyor lifts
- Packaging machine vertical actuators
Installation guidelines:
Ensure guide rods are parallel to mounting surface within 0.2mm/m tolerance.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 50mm clearance behind cylinder for stroke extension.
Critical note:
Maximum side moment load decreases by 15% when operating at temperatures
above 60℃. Use heat-resistant seals (option code -HR) for continuous
high-temperature applications.
| Property | Property Value |
|---|---|
| sku | TSAIL100X200S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | <200mm> |
| Bearing Category | Linear Bearing |
