Airtac TSAIL Guided Cylinder TSAIL100X250S
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Series Guided Cylinder TSAIL100X250S Technical Details
- Model: TSAIL100X250S
- Bore size: Ø100mm
- Stroke: 250mm
- Operating pressure: 0.1–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Fixed MF1/MF2 type (front/rear flange)
- Port size: G3/8 (NPT1/2 optional)
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Cylinder tube: Hard anodized aluminum alloy
- Guide mechanism: Dual linear ball bearings with recirculating system
- Max lateral load capacity: 1,800N
- Temperature range: -20℃ to 80℃
- Weight: 9.8kg (excluding accessories)
- Dimensions: 588mm(L) × 142mm(W) × 142mm(H)
- Lubrication: Pre-lubricated (Relubrication interval: 3,000km stroke)
- Protection rating: IP54 (standard), IP67 (optional w/rod cover)
High-rigidity guided cylinder with integrated linear guidance system, engineered for precision linear motion under heavy moment loads. Features hardened guide rails with ±0.05mm repeat positioning accuracy and anti-corrosion surface treatment. The dual-bearing structure eliminates rotational play, making it ideal for vertical Z-axis applications. Requires 40μm filtered air with <20μm particulate in lubrication oil (ISO 8573-1 class 4).
- Automated press-fit systems for automotive assembly
- Die-casting machine ejector mechanisms
- PCB depaneling machine support actuators
- Heavy-duty material clamping in CNC fixtures
- Vertical lifting platforms in warehouse automation
Installation guidelines:
Maintain ≤0.1mm/m parallelism between guide rail and motion axis.
Use torque wrench for mounting bolts (35±5 N·m). Apply silicone grease
to guide shafts during maintenance. Avoid side-impact loads exceeding
1,500N during operation.
| Property | Property Value |
|---|---|
| sku | TSAIL100X250S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | <250MM> → <250mm> |
| Bearing Category | Linear Bearing |
