Airtac TSAIL Guided Cylinder TSAIL100X300
$840.98
Regular price
$848.48
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X300
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Maintenance tip:
Apply lithium-based grease (ISO viscosity grade 32) every 6 months or 5 million cycles.
Always maintain perpendicular alignment between load direction and guide rails to prevent premature wear.
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Series Guided Cylinder TSAIL100X300 Technical Details
- Model: TSAIL100X300
- Type: Double-acting guided cylinder with precision linear guides
- Bore size: Ø100mm
- Stroke: 300mm
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Side flange mounting (ISO 15552 standard)
- Port size: 1/4" NPT (G1/4 optional)
- Guide mechanism: Dual-axis hardened steel linear rails
- Rod material: Chrome-plated steel (JIS S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile) wiper and seals
- Temperature range: -10℃ to +80℃
- Protection rating: IP54 (standard), IP67 (optional)
- Lubrication: Pre-lubricated (relubrication interval: 2000km)
- Repeat positioning accuracy: ±0.05mm
- Max lateral load capacity: 2000N
- Weight: 5.8kg (excluding accessories)
- Dimensions: 465mm(L) × 108mm(W) × 125mm(H)
High-rigidity guided cylinder featuring dual-axis linear motion guidance system with exceptional moment resistance (Pitch/Yaw/Roll moments: 150/150/200 N·m respectively). The T-shaped guide block design eliminates rotational movement while maintaining smooth linear motion, making it ideal for precision alignment applications. Integrated shock absorbers prevent end-impact damage during high-speed operation.
Industrial Applications:
- Precision palletizing robots in logistics automation
- Glass panel transfer systems with vacuum end effectors
- Die-casting machine core-pulling mechanisms
- PCB drilling equipment Z-axis positioning
- Automotive welding fixture positioning
Maintenance tip:
Apply lithium-based grease (ISO viscosity grade 32) every 6 months or 5 million cycles.
Always maintain perpendicular alignment between load direction and guide rails to prevent premature wear.
Configuration Options:
- Rod end types: Female thread (M20×1.5), double rod, or clevis ends
- Position sensing: Built-in magnet for cylinder sensors (SM/SD series compatible)
- Custom strokes available from 50mm to 1000mm
- High-temperature variant (up to 120℃) with FKM seals
| Property | Property Value |
|---|---|
| sku | TSAIL100X300 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 300mm |
| Bearing Category | Linear Bearing |
