Airtac TSAIL Guided Cylinder TSAIL100X350
$860.73
Regular price
$868.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X350
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation protocol:
Requires torque-controlled mounting (18-22Nm for M10 fasteners) with
perpendicularity tolerance ≤0.1mm/100mm. Pre-lubricated - do not
disassemble guide blocks during installation. Use AirTAC PXS-1 grease
for maintenance every 500km of cumulative travel.
Load limitations:
Max allowable moment 850N·m (My), 650N·m (Mz). For pulsating loads
above 3Hz, reduce dynamic load capacity by 30%.
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Series Guided Frame Cylinder TSAIL100X350 Technical Details
- Model: TSAIL100X350
- Type: Guided frame cylinder with precision linear guides
- Bore size: Ø100mm
- Stroke: 350mm (standard), customizable up to 1000mm
- Guide type: Twin-axis heavy-duty roller bearings
- Mounting style: Front flange MF1 (ISO 15552 compatible)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable hydraulic buffer (both ends)
- Port size: G3/8 (NPT1/2 optional)
- Seal material: HNBR + polyurethane (high wear resistance)
- Protection rating: IP54 (standard), IP67 optional
- Weight: 14.5kg (±2%)
- Dimensions (L×W×H): 678mm × 210mm × 125mm
- Guide block material: Hard-anodized aluminum alloy
- Piston rod coating: Hard chrome-plated (20-25μm)
Heavy-duty guided cylinder combining pneumatic actuation with mechanical guidance system, designed for applications requiring exceptional moment resistance and alignment precision. Features dual linear guides with 4-row ball bearing structure capable of handling 4× higher lateral loads compared to standard cylinders. Integrated shock absorbers reduce end-impact vibration by 60%.
Industrial Applications:
- Vertical lifting systems in automotive welding fixtures
- Precision positioning in semiconductor wafer handling
- Die-casting machine ejection mechanisms
- Press-fit assembly of heavy components
- Automated palletizing systems with side loads
Installation protocol:
Requires torque-controlled mounting (18-22Nm for M10 fasteners) with
perpendicularity tolerance ≤0.1mm/100mm. Pre-lubricated - do not
disassemble guide blocks during installation. Use AirTAC PXS-1 grease
for maintenance every 500km of cumulative travel.
Load limitations:
Max allowable moment 850N·m (My), 650N·m (Mz). For pulsating loads
above 3Hz, reduce dynamic load capacity by 30%.
| Property | Property Value |
|---|---|
| sku | TSAIL100X350 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 350mm |
| Bearing Category | Linear Bearing |
