Airtac TSAIL Guided Cylinder TSAIL100X350S
$866.31
Regular price
$873.81
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X350S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation guidelines:
Ensure guide rail alignment within 0.1mm/m parallel tolerance.
Apply Molykote EM-30L grease during maintenance.
Maximum allowable misalignment: 0.5° angular deviation.
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL100X350S Guided Cylinder with Integrated Linear Guide
- Model: TSAIL100X350S
- Type: Guided cylinder with integrated linear guide block
- Bore size: Ø100mm
- Stroke: 350mm (standard) | Customizable up to 2000mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Guide type: Heavy-duty linear ball bearing guide
- Mounting: Front flange (MF1) with 4-M10x1.5 mounting holes
- Port size: G1/2 (NPT1/2 optional)
- Seal material: NBR + PU combination
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (relubrication required every 5000km)
- Weight: 4.8kg (excluding accessories)
- Dimensions: 470mm(L) × 120mm(W) × 100mm(H)
- Guide block load capacity: 12kN vertical / 6kN lateral
- Repeat accuracy: ±0.05mm
- Piston rod material: SCM435 chrome-plated steel
High-rigidity guided cylinder featuring dual-axis linear motion control, designed for precision positioning under heavy side loads. The integrated linear guide block eliminates piston rotation and provides exceptional moment resistance. Features corrosion-resistant construction with IP54 protection rating, suitable for harsh industrial environments.
Typical Applications:
- Automated production line material handling systems
- Automotive welding fixture positioning
- Die-casting machine core-pulling mechanisms
- Precision glass panel transfer devices
- Heavy-duty clamping in CNC machining centers
Installation guidelines:
Ensure guide rail alignment within 0.1mm/m parallel tolerance.
Apply Molykote EM-30L grease during maintenance.
Maximum allowable misalignment: 0.5° angular deviation.
Cycle considerations:
Optimal performance at ≤500mm/s piston speed.
Recommend using AirTAC ASC-200 series speed controllers
for precise end cushion adjustment.
| Property | Property Value |
|---|---|
| sku | TSAIL100X350S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 350mm |
| Bearing Category | Linear Bearing |
