Airtac TSAIL Guided Cylinder TSAIL100X400S
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL100X400S Guided Rod Cylinder Specifications
- Model: TSAIL100X400S
- Type: Guided rod cylinder with integrated linear guides
- Bore size: Ø100mm
- Stroke: 400mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Mounting type: Front flange MF1 & rear flange MF2
- Guide rail type: Dual-axis square rail system
- Guide stroke accuracy: ±0.1mm/m
- Seal material: Polyurethane (PU) with wear-resistant rings
- Temperature range: -10℃ to 80℃
- Weight: 5.8kg (without accessories)
- Dimensions: 580mm(L) × 100mm(W) × 150mm(H)
- Port size: G3/8 (NPT1/4 optional)
- Lubrication: Pre-lubricated (regreasing possible via Zerk fittings)
Heavy-duty guided cylinder combining pneumatic actuation with precision linear guidance, engineered for applications requiring exceptional moment resistance and positional stability. Features dual-axis hardened steel rails with four-row ball bearing carriages, capable of handling 360° rotational moments up to 850N·m. Includes anti-corrosion treatment for industrial environments.
- Precision press tooling alignment systems
- Automated material transfer arms
- CNC machine tool clamping mechanisms
- High-precision glass handling equipment
- Automotive welding fixture positioning
Installation note:
Requires parallel alignment within 0.2mm/m using precision level during mounting.
For full load capacity, maintain ambient temperature below 60℃ with relative humidity <80% RH.
- Pre-commissioning: Perform 50 low-pressure (0.1MPa) test cycles
- Lubrication interval: 500km travel distance or 6 months
- Max side load capacity: 2,500N vertical / 1,800N horizontal
- Alignment tolerance: ±0.5° angular misalignment compensation
| Property | Property Value |
|---|---|
| sku | TSAIL100X400S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | <400mm> |
| Bearing Category | Linear Bearing |
