Airtac TSAIL Guided Cylinder TSAIL100X450
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Series Guided Cylinder TSAIL100X450 Technical Details
- Model: TSAIL100X450
- Bore size: 100mm
- Stroke: 450mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable air cushion (both ends)
- Guide mechanism: Dual-axis adjustable linear guide with recirculating ball bearings
- Mounting style: MF1 (front flange with through holes)
- Port size: G3/8 (NPT1/2 optional)
- Piston rod thread: M20×1.5
- Seal material: Polyurethane (NBR available on request)
- Protection rating: IP54 (IP67 with optional wiper)
- Weight: 8.7kg (excluding accessories)
- Dimensions: 700mm(L) × 200mm(W) × 150mm(H)
Heavy-duty guided cylinder combining pneumatic actuation with precision linear guidance, featuring hardened steel guide rails and preloaded bearing blocks. The dual-axis design eliminates rotational movement while handling moment loads up to 180N·m. Integrated grease fittings allow maintenance without disassembly.
- Vertical lifting systems in automotive welding lines
- Precision glass panel handling robots
- Die-casting machine ejector mechanisms
- PCB depaneling equipment with side-load compensation
- Automated warehouse stacker positioning
Installation protocol:
Requires parallel alignment within 0.2mm/m using laser measurement.
Lubricate guide rails with ISO VG32 hydraulic oil before initial operation.
Maximum side load capacity 1500N (X/Y axes).
| Property | Property Value |
|---|---|
| sku | TSAIL100X450 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 450mm |
| Bearing Category | Linear Bearing |
