Airtac TSAIL Guided Cylinder TSAIL100X450S
$905.65
Regular price
$913.15
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X450S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation note:
Requires precise parallelism adjustment (≤0.1mm/m) between guide rails and load path.
Use torque wrench for mounting bolts (35-40N·m). Maintain 0.5mm clearance between
stopper plates and guide blocks during alignment.
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL100X450S Guided Rod Cylinder Specifications
- Model: TSAIL100X450S
- Series: TSAIL Guided Rod Cylinder Series
- Bore size: Ø100mm
- Stroke: 450mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable hydraulic buffer (both ends)
- Guiding mechanism: Twin linear ball bearings
- Rod material: Chrome-plated steel (S45C)
- Cylinder tube: Aluminum alloy (hard anodized)
- Seal material: NBR + Polyurethane hybrid
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (Molykote EM-50L)
- Port size: G3/8 (alternative NPT1/2 available)
- Mounting type: Standard MF1 flange with guide rail base
- Weight: 8.2kg ±2% (excluding accessories)
- Dimensions: 690mm(L) × 210mm(W) × 210mm(H)
- Side load capacity: ≤800N (guide rail section)
- Repeat positioning accuracy: ±0.05mm
- Protection rating: IP54 (standard), IP67 optional
Heavy-duty guided cylinder with integrated linear motion system, combining pneumatic actuation and precision guidance in one compact unit. Features dual-path lubrication channels and anti-rotation design for stable load handling. The hardened guide rails withstand 3,500N dynamic lateral forces, making it ideal for applications requiring precise linear motion under heavy side loads.
Typical Applications:
- Automated welding fixture positioning systems
- Die-casting machine core-pulling mechanisms
- Automotive assembly line pallet transfer
- Glass panel vacuum lifting systems
- CNC machine tool automatic door actuators
Installation note:
Requires precise parallelism adjustment (≤0.1mm/m) between guide rails and load path.
Use torque wrench for mounting bolts (35-40N·m). Maintain 0.5mm clearance between
stopper plates and guide blocks during alignment.
Maintenance:
Relubricate guide rails every 3 months or 500km of travel (whichever comes first).
Monitor buffer adjustment marks - optimal position when piston deceleration completes
5mm before end cover. Replace wear bands if lateral play exceeds 0.2mm.
| Property | Property Value |
|---|---|
| sku | TSAIL100X450S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 450mm |
| Bearing Category | Linear Bearing |
