Airtac TSAIL Guided Cylinder TSAIL100X500S
$925.40
Regular price
$932.90
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X500S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation guidelines:
Requires parallel alignment within 0.2mm/m. Use torque wrench (45N·m) for guide block bolts.
Lubricate guide rails weekly in high-cycle applications (＞500 cycles/day).
Critical notes:
Not compatible with lateral impact loads. Requires FRL unit with 5μm filtration.
Avoid rapid decompression (＜0.3 MPa/sec) to prevent seal damage.
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL100X500S Guided Rod Cylinder Specifications
- Model: TSAIL100X500S
- Type: Double-acting guided cylinder with precision linear guides
- Bore size: Ø100mm
- Stroke: 500mm (customizable 50-1000mm)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushion type: Adjustable rubber buffer + shock absorber
- Guide mechanism: Dual linear ball bearings (preloaded)
- Mounting style: Front flange MF1 (ISO 15552 standard)
- Port size: G3/8 (NPT1/2 optional)
- Piston rod material: Hard chrome-plated SCM435 steel
- Seal material: NBR + PU hybrid seals
- Repeat positioning accuracy: ±0.05mm
- Max speed: 500-800 mm/s (lubricated)
- Side load capacity: 1500N (X/Y axes)
- Protection rating: IP54 (standard), IP67 with optional kit
- Weight: Approx. 25kg (excluding accessories)
- Dimensions: 705mm(L) × 200mm(W) × 150mm(H)
- Lubrication: Pre-lubed (Grease NBU15), maintenance interval: 500km travel
Heavy-duty guided cylinder featuring integrated high-rigidity linear guides that eliminate rotational movement. The T-shaped guide block design provides exceptional moment resistance (300Nm anti-torque capacity) for precision vertical/horizontal operations. Includes magnetic piston for position sensing (sensor not included).
Industrial Applications:
- Automated welding fixture positioning in automotive lines
- Vertical lifting mechanisms for solar panel handling
- Precision press-fit operations in electronics assembly
- Pallet shuttle systems in automated warehouses
- Glass handling robots with vacuum grippers
Installation guidelines:
Requires parallel alignment within 0.2mm/m. Use torque wrench (45N·m) for guide block bolts.
Lubricate guide rails weekly in high-cycle applications (＞500 cycles/day).
Critical notes:
Not compatible with lateral impact loads. Requires FRL unit with 5μm filtration.
Avoid rapid decompression (＜0.3 MPa/sec) to prevent seal damage.
| Property | Property Value |
|---|---|
| sku | TSAIL100X500S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 500mm |
| Bearing Category | Linear Bearing |
