Airtac TSAIL Guided Cylinder TSAIL32X100S
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Guided Cylinder TSAIL32X100S Technical Details
- Model: TSAIL32X100S
- Bore size: 32mm
- Stroke: 100mm
- Mounting type: ISO 15552 standard (VDMA 24562)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Port size: G1/8 (M5 optional)
- Guide rail type: Dual linear ball bearings
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal material: NBR/PU compound
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (DOP-free)
- Protection rating: IP54 (standard), IP67 (optional)
- Weight: 2.85kg (±2%)
- Dimensions:
- Total length: 308mm (including guide rail)
- Body width: 68mm
- Height with guide: 85mm
- Centerline height: 40mm
Precision-guided cylinder with integrated linear motion system, featuring anti-rotation stability and ±0.05mm repeat positioning accuracy. The dual ball bearing guide rail minimizes deflection under side loads up to 150N. Hermetically sealed sensors slots (M5x0.8) on both ends enable position feedback integration.
- Precision assembly line vertical lifting mechanisms
- CNC machine tool automatic tool changers
- Glass panel handling systems
- Automated optical inspection (AOI) equipment
- Robotic welding fixture positioning
Installation guidelines:
Mounting surface flatness ≤0.1mm/m. Use torque-controlled tightening (guide rail bolts: 4.5-5.5N·m).
Lubricate guide rails with ISO VG32 hydraulic oil during maintenance.
| Property | Property Value |
|---|---|
| sku | TSAIL32X100S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
| Bearing Category | Linear Bearing |
