Airtac TSAIL Guided Cylinder TSAIL32X250S
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL32X250S Guided Rod Cylinder Technical Details
- Model: TSAIL32X250S
- Type: Double-acting guided rod cylinder
- Bore size: 32mm
- Stroke: 250mm
- Guide type: Dual-axis rectangular slide rail
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: M5x0.8 (standard), G1/8 optional
- Mounting: Base mounting with 4x M5 threaded holes
- Piston rod material: Chrome-plated carbon steel (S45C)
- Cylinder tube: Hard anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Protection rating: IP54 (standard), IP67 optional
- Weight: 2.45kg ±3%
- Dimensions (L×W×H):
- Total length: 408mm (stroke 250 + 158mm body)
- Rail width: 60mm
- Height (including rail): 72mm
Precision guided cylinder with integrated slide rail system, engineered for applications requiring high moment resistance and positional accuracy. Features dual-axis guidance with linear ball bearings (LMB) that provide ≤0.05mm lateral play. The hardened rail surface (HRC50+) ensures wear resistance under heavy side loads. Requires lubrication-free operation with filtered air (5-40μm).
- Vertical lifting mechanisms in assembly robots
- Precision clamping fixtures for CNC machining
- Material transfer systems with lateral force requirements
- Packaging equipment needing anti-rotation stability
- Automated test stands requiring repeat positioning (±0.1mm)
Installation tip:
Align guide rails parallel to mounting surface within 0.1mm/m tolerance.
Use mounting torque of 3.5-4.2N·m for M5 screws. Apply Loctite 243
to thread fasteners in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | TSAIL32X250S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <32 mm> |
| Stroke | <250MM> → <250mm> |
| Bearing Category | Linear Bearing |
