Airtac TSAIL Guided Cylinder TSAIL32X300S
$269.36
Regular price
$276.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL32X300S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Use flexible couplings when connecting to driven components. Perform initial 50-stroke break-in cycle at 0.3MPa before full pressure operation. Lubricate guide shafts monthly in continuous operation environments.
Critical note:
Do NOT use as vertical load-bearing structure without external safety brake. Maximum side load capacity: 200N perpendicular to rod axis. Avoid rapid pressure changes >0.5MPa/100ms to prevent bushing wear.
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL32X300S Guided Rod Cylinder Technical Details
- Model designation: TSAIL32X300S
- Cylinder type: Double-acting with integrated guide mechanism
- Bore size: Ø32 mm (ISO 6432 standard)
- Stroke length: 300 mm (±0.5mm tolerance)
- Operating pressure range: 0.1–0.9 MPa
- Port thread: G1/4 (BSPP) dual ports with M5x0.8 pilot valve thread
- Cushioning type: Adjustable rubber buffers at both ends
- Guide structure: Dual 12mm chrome-plated shafts with linear bushings
- Piston rod material: SCM435 steel with hard chrome plating (25μm)
- Seal type: NBR seals with wear-resistant ring (FDA compliant option available)
- Ambient temperature: -20℃ to +80℃ (non-freezing)
- Mounting options: Front flange MF12, rear foot mounting FF12
- Weight: 4.5 kg (with standard accessories)
- Dimensions: 500mm(L) × 130mm(W) × 85mm(H)
- Protection class: IP54 (dust protected & water splashed)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if re-lubing)
Precision-guided pneumatic cylinder combining thrust and anti-rotation functions through integrated linear guides. Features dual hardened shafts for enhanced moment resistance (30N·m max) with T-slot mounting surfaces for accessory attachment. The anodized aluminum body ensures corrosion resistance in humid environments.
Industrial Applications:
- Vertical lifting mechanisms in automated assembly lines
- Precision positioning in semiconductor handling equipment
- Clamping fixtures requiring anti-rotation stability
- Packaging machinery with side load requirements
- Automated welding jigs needing vibration resistance
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Use flexible couplings when connecting to driven components. Perform initial 50-stroke break-in cycle at 0.3MPa before full pressure operation. Lubricate guide shafts monthly in continuous operation environments.
Critical note:
Do NOT use as vertical load-bearing structure without external safety brake. Maximum side load capacity: 200N perpendicular to rod axis. Avoid rapid pressure changes >0.5MPa/100ms to prevent bushing wear.
| Property | Property Value |
|---|---|
| sku | TSAIL32X300S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <32 mm> |
| Stroke | 300mm |
| Bearing Category | Linear Bearing |
