Airtac TSAIM Cylinder with Guide Bracket TSAIM100X100
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X100 Guided Rod Cylinder Technical Details
- Model: TSAIM100X100
- Bore size: Ø100mm
- Stroke: 100mm (Standard), customizable up to 500mm
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-750 mm/s
- Cushioning: Adjustable hydraulic shock absorber
- Mounting type: Fixed MF1/MF2 with dual guide rods
- Rod end thread: M20×1.5 (Standard), M16/M24 optional
- Port size: G3/8 (NPT1/4 optional)
- Ambient temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated (Use ISO VG32 oil if required)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal type: NBR seals (FKM available for high-temp)
- Weight: 12.8 kg (with standard accessories)
- Dimensions: 560mm(L) × 165mm(W) × 165mm(H)
- Max lateral load: 800N (Guide rod capacity)
- Repeat positioning accuracy: ±0.05mm
Heavy-duty guided cylinder with integrated dual-axis linear guides, designed for high moment load resistance and precise linear motion. Features anti-rotation mechanism through twin guide rods and precision ground bearing surfaces. Includes wear-resistant guide bushings rated for 5,000km service life under normal loads.
- Automated palletizing systems requiring anti-torsion stability
- Press machine tooling with side load compensation
- Precision glass panel handling equipment
- Automotive welding fixture positioning
- Die-casting machine ejection mechanisms
Installation guidelines:
Mount on machined surface with flatness ≤0.1mm/m. Apply Loctite 243
to guide rod mounting bolts (35-40 N·m torque). Perform parallel
alignment within 0.05mm/m between guide rods during assembly.
| Property | Property Value |
|---|---|
| sku | TSAIM100X100 |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
