Airtac TSAIM Cylinder with Guide Bracket TSAIM100X100S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X100S Guided Rod Cylinder Specifications
- Model: TSAIM100X100S
- Type: Double-acting guided cylinder with integrated linear bearings
- Bore size: Ø100mm
- Stroke: 100mm (standard), customizable up to 500mm
- Operating pressure: 0.1–0.9 MPa
- Piston rod material: Hard chrome-plated carbon steel (JIS S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile) with wear-resistant ring
- Guide mechanism: 4 precision linear ball bearings
- Mounting type: Front flange MF1 (ISO 15552 compatible)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (relubrication interval: 3,000km)
- Weight: 12.8kg (excluding accessories)
- Dimensions: 580mm(L) × 180mm(W) × 180mm(H)
- Port size: G1/2 (BSPP thread)
- Position detection: Magnet compatible (sensor slots on both sides)
- ISO standard: 15552 (formerly ISO 6431)
Heavy-duty guided cylinder engineered for precision linear motion under high moment loads. Features four-row linear ball bearing guidance system that eliminates rotational movement, maintaining ±0.05mm lateral runout accuracy. The reinforced aluminum construction with double-sealed piston provides 50% higher side load capacity compared to standard cylinders. Includes anti-vibration pads and wear indicators.
- Precision press brake tool positioning systems
- Automated welding fixture alignment
- Die-casting machine ejector mechanisms
- Glass handling robotic end effectors
- Semiconductor wafer transfer systems
- Heavy conveyor gate actuators
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm/m. Use alignment jigs during installation
to prevent bearing preload deformation. Lubricate guide rails with ISO VG32 hydraulic oil
before initial operation.
| Property | Property Value |
|---|---|
| sku | TSAIM100X100S |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
