Airtac TSAIM Cylinder with Guide Bracket TSAIM100X250S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X250S Guided Rod Cylinder Specifications
- Model: TSAIM100X250S
- Type: Double-acting guided cylinder with precision linear guides
- Bore size: Ø100mm
- Stroke: 250mm
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Guide mechanism: 4-row ball bearing system with hardened steel rails
- Max lateral load: 500N (at center position)
- Max moment load: 150N·m (static), 75N·m (dynamic)
- Seal material: Nitrile Butadiene Rubber (NBR) with wear-resistant rings
- Temperature range: -20℃ to +80℃ (-4°F to +176°F)
- Port size: 1/2" NPT (G1/2 optional)
- Weight: 6.5kg (14.3 lbs) ±3%
- Dimensions: 500mm(L) × 200mm(W) × 200mm(H)
- Rod material: Chrome-plated steel rod (SUJ2 equivalent)
- Repeat positioning accuracy: ±0.05mm
- ISO standard: 15552 (VDMA 24562, CETOP RP52P)
Industrial-grade guided cylinder featuring integrated linear guides that eliminate rotational movement, designed for high moment load applications requiring exceptional alignment stability. The dual-piston design with 4-point guidance system ensures smooth operation under eccentric loads up to 50% of maximum capacity. Includes magnetic piston for position sensing compatibility.
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms for heavy palletizers
- Automated welding fixture positioning systems
- Glass panel handling in LCD manufacturing
- Die-casting machine core-pulling mechanisms
Installation requirements:
Mount on machined surface with flatness ≤0.1mm/m. Lubricate guide rails with ISO VG32 hydraulic oil
before initial operation. Avoid side-mounted piping - use rear port connections for optimal performance.
| Property | Property Value |
|---|---|
| sku | TSAIM100X250S |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
