Airtac TSAIM Cylinder with Guide Bracket TSAIM100X300
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X300 Guided Rod Cylinder Specifications
- Model: TSAIM100X300
- Type: Double-acting guided cylinder with precision linear bearings
- Bore size: Ø100mm
- Stroke: 300mm (customizable 25-2000mm)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Rod diameter: Ø25mm chromium-plated steel
- Guide rod: 2×Ø20mm hardened steel with special surface treatment
- Mounting style: Front flange (MF1) with integrated guide block
- Max lateral load: 1,500N (X-axis), 1,200N (Y-axis)
- Theoretical force: 706N (at 0.6MPa)
- Seal material: High-grade NBR with wear-resistant ring
- Temperature range: -20℃ to +80℃
- Weight: 8.5kg (excluding accessories)
- Dimensions: 400mm(L) × 150mm(W) × 120mm(H)
- Port size: G1/2 (optional NPT1/2)
- Lubrication: Pre-lubricated (Grease-free operation)
- Protection rating: IP54 (standard), IP67 optional
- Sensor compatibility: Built-in magnet for proximity switches
Heavy-duty guided cylinder engineered for precision linear motion under high moment loads. Features dual hardened guide rods with linear ball bearings for enhanced rigidity and alignment accuracy. The anodized aluminum body with corrosion-resistant coating ensures durability in harsh environments. Integrated mounting surfaces allow direct tooling attachment.
- Precision press mechanisms in automotive stamping
- Vertical lifting systems for material handling robots
- Positioning stages in semiconductor manufacturing
- Clamping fixtures for CNC machining centers
- Packaging machinery with side load requirements
Installation note:
Ensure parallel alignment of guide rods within 0.1mm/m tolerance. Use only with guided-type couplings when connecting to driven components. Perform monthly inspection of bearing clearance (max 0.05mm play allowed).
Critical parameters:
Maximum permissible offset load moment: 450N·mMaximum speed: 500mm/s (with cushion adjustment)
Do not exceed 80% of theoretical force in continuous duty cycles
| Property | Property Value |
|---|---|
| sku | TSAIM100X300 |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
