Airtac TSAIM Cylinder with Guide Bracket TSAIM100X300S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X300S Guided Cylinder Specifications
- Model: TSAIM100X300S
- Type: Guided rod cylinder with precision linear bearings
- Bore size: Ø100mm
- Stroke: 300mm (customizable 250-500mm)
- Operating pressure: 0.1-1.0 MPa
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Mounting: Standard MF1 flange with 4×M10 mounting holes
- Port size: G3/8 (NPT1/2 optional)
- Operating temperature: -10℃ to 80℃
- Seal material: NBR + Polyurethane hybrid seals
- Guide mechanism: Dual 25mm hardened chrome shafts with 4 linear ball bushings
- Repeat positioning accuracy: ±0.05mm
- Max lateral load: 1800N (static), 900N (dynamic)
- Piston rod material: SCM435 chrome-plated steel
- Sensor slots: 2×M5 slots for magnetic switches (sensors not included)
- Weight: 12.8kg (without accessories)
- Dimensions: 648mm(L) × 148mm(W) × 128mm(H)
Heavy-duty guided cylinder engineered for precision motion control under high moment loads. Features four-point linear bearing guidance system that eliminates rotational movement, making it ideal for applications requiring strict alignment. The reinforced flange design withstands 3× higher side loads compared to standard cylinders. Requires ISO 8573-1:2010 Class 3 lubricated air.
- Precision press-fit operations in automotive assembly
- Vertical lifting systems with guided tooling plates
- PCB depaneling machines requiring vibration-free motion
- Glass handling systems with vacuum end effectors
- Automated welding jigs with positional accuracy requirements
Installation note:
Always preload guide bushings with 0.02-0.05mm clearance using alignment jigs.
Lubricate guide shafts weekly with ISO VG32 hydraulic oil. Avoid angular loads exceeding 0.5° misalignment.
| Property | Property Value |
|---|---|
| sku | TSAIM100X300S |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
