Airtac TSAIM Cylinder with Guide Bracket TSAIM100X350S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X350S Guided Rod Cylinder Technical Details
- Model Code: TSAIM100X350S
- Bore Size: Ø100mm (ISO standard)
- Stroke: 350mm (adjustable cushioning)
- Operating Pressure: 0.1-0.8 MPa
- Guiding Type: Dual-axis hardened steel rods with linear bearings
- Max Side Load Capacity: 2000N (X/Y axes)
- Piston Rod: Chrome-plated steel Ø25mm
- Port Size: G3/8 (NPT1/2 optional)
- Seal Material: NBR + Polyurethane combination
- Temperature Range: -20℃ to 80℃
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Weight: 12.8kg ±2% (with mounting brackets)
- Dimensions: 650mm(L) × 180mm(W) × 180mm(H)
- Mounting: Standard front flange + rear foot mounting
- Repeat Positioning Accuracy: ±0.2mm
- IP Rating: IP54 (IP67 with optional bellows)
Heavy-duty guided cylinder featuring integrated anti-rotation mechanism through precision-ground guide rods. The dual-axis design provides exceptional moment resistance, making it ideal for applications requiring precise linear motion under substantial side loads. Incorporates adjustable pneumatic cushions at both ends for smooth deceleration.
- Automated palletizing systems with heavy payloads
- Precision glass panel handling equipment
- Injection molding machine ejector mechanisms
- Automotive welding fixture positioning
- Press tooling alignment systems
Installation guidelines:
Ensure guide rods are parallel to mounting surface within 0.1mm/m tolerance.
Use alignment jigs during installation to prevent binding. Lubricate guide shafts
every 500km of travel using ISO VG32 hydraulic oil.
- Max piston speed: 0.5m/s (with cushioning engaged)
- Minimum cycle time: 1.2 seconds (full stroke)
- Lateral stiffness: 500N/0.01mm deflection
| Property | Property Value |
|---|---|
| sku | TSAIM100X350S |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
