Airtac TSAIM Cylinder with Guide Bracket TSAIM100X500
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X500 Guided Cylinder with Guide Frame Specifications
- Model: TSAIM100X500
- Type: Double-acting guided cylinder with integrated linear bearings
- Bore size: 100mm
- Stroke: 500mm (±0.5mm precision)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable hydraulic buffer (both ends)
- Mounting style: Horizontal flange (MF1) with 4×M10 threaded holes
- Guide mechanism: Dual-axis roller bearing system
- Rod material: Hard chrome-plated steel (0.02μm Ra surface finish)
- Seal type: HNBR seals with wear-resistant ring
- Temperature range: -10℃ to 80℃
- Weight: 18.7kg (excluding accessories)
- Dimensions: 780mm(L) × 195mm(W) × 165mm(H)
- Max lateral load capacity: 1,200N
- Max moment tolerance: 850N·m
- Air port size: G3/8 (standard) / NPT1/2 (optional)
- Lubrication: Pre-lubricated (relubrication interval: 2,000km)
High-rigidity guided cylinder engineered for precision linear motion under heavy side loads. Features integrated roller guides that eliminate piston rod rotation while maintaining ±0.1mm repeat positioning accuracy. The hardened stainless steel guide rails and dual-axis bearing system enable smooth operation at speeds up to 1.5m/s. Requires 40μm filtered dry air with ISO VG32 lubricator oil (optional oil-free operation available).
- Vertical lifting mechanisms in automotive assembly lines
- Precision glass panel handling robots
- Heavy-duty clamping fixtures for CNC machining centers
- Packaging machine product alignment systems
- Semiconductor wafer transfer equipment
Installation tip:
Align guide rails within 0.2mm/m parallelism tolerance using precision level.
Apply initial lubrication to guide blocks before first operation.
Avoid side impact forces exceeding 800N during maintenance.
| Property | Property Value |
|---|---|
| sku | TSAIM100X500 |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
