Airtac TSAIM Cylinder with Guide Bracket TSAIM32X150
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM32X150 Guided Rod Cylinder Specifications
- Series: TSAIM (Guided Cylinder with Integral Mounting Bracket)
- Bore size: 32mm
- Stroke: 150mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Cushioning: Elastic buffer + hydraulic shock absorber
- Guide type: Dual linear ball bearings (pre-loaded)
- Rod material: Hard chrome-plated carbon steel
- Seal material: NBR + Polyurethane (Oil & wear resistant)
- Repeat positioning accuracy: ±0.01mm
- Max lateral load: 180N (at guide block)
- Weight: 2.85kg (with bracket)
- Dimensions:
- Length: 236mm (Stroke 150 + Minimum retracted length)
- Width: 56mm (Guide block width)
- Height: 62mm (Including mounting bracket)
- ISO standard: 6431 (Modified)
- Protection rating: IP54 (Dust & splash resistant)
Precision guided cylinder featuring integrated linear guides and rigid aluminum bracket, designed for applications requiring exceptional lateral load capacity and positional stability. The dual ball bearing guidance system eliminates rotational play, while the oil-impregnated bronze bushings ensure smooth operation. Includes magnetic piston for position sensing compatibility.
- Precision alignment in semiconductor wafer handling robots
- Vertical lifting mechanisms for CNC tool changers
- Parallel gripper actuation in pick-and-place systems
- Position locking in automated welding fixtures
- Material press-fitting operations with side force compensation
Installation guidelines:
Mount on machined surface with flatness ≤0.1mm. Apply M6x1.0 mounting screws
(Grade 8.8 or higher) with 12N·m torque. Lubricate guide rails with ISO VG32
hydraulic oil before initial operation. Avoid side-mounted piping to prevent
moment load interference.
| Property | Property Value |
|---|---|
| sku | TSAIM32X150 |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
