Airtac TSAIM Cylinder with Guide Bracket TSAIM32X300S
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM32X300S Guided Rod Cylinder Technical Specifications
- Model: TSAIM32X300S
- Bore size: 32mm
- Stroke: 300mm (±1.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Piston speed: 50–800 mm/s (lubricated)
- Guiding mechanism: Dual chrome-plated steel rods (16mm diameter)
- Guiding accuracy: ±0.1mm repeatability
- Mounting type: Front flange (MF1) with reinforced base
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: 1/4" NPT (G1/8 optional)
- Seal material: NBR (Nitrile) standard / PU optional
- Temperature range: -20℃ to 80℃
- Weight: 3.5kg (without accessories)
- Dimensions: 450mm(L) × 100mm(W) × 80mm(H)
- Rod end thread: M10×1.25 (male)
- ISO certification: 6431/VDMA 24562 standards
Precision-guided pneumatic cylinder with integrated linear bearing system, designed for applications requiring exceptional lateral load capacity (up to 180N) and alignment accuracy. Features double-sealed guide rods with chromium plating (HRC 58-62 hardness) for wear resistance. Optional magnetic piston version (TSAIM32X300S/M) available for position feedback.
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms for CNC machine tool changers
- Glass panel handling systems with anti-rotation requirements
- High-cycle packaging equipment with side-mounted tooling
- Automated welding jigs requiring vibration resistance
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Apply ISO VG32 hydraulic oil
to guide rods weekly in continuous operation. Avoid angular loads exceeding 2° deviation.
For horizontal installations, use optional support rails (TSAIM-SUP32).
- Maximum side load: 180N at mid-stroke
- Lubrication interval: 500km travel distance or 3 months
- Re-greasing requirement: 2cc of lithium soap grease every 6 months
- Bending moment limit: 45N·m
| Property | Property Value |
|---|---|
| sku | TSAIM32X300S |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
