Airtac TTG Stopper Cylinder TTG32X15R
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Stopper Cylinder TTG32X15R Technical Details
- Full model: TTG32X15R
- Bore size: Φ32mm
- Stroke: 15mm
- Operation type: Double acting
- Working pressure: 0.05-0.9 MPa
- Cushioning: Adjustable rubber buffer + air cushion
- Mounting style: Front flange with locating pins (ISO 15552 standard)
- Port size: G1/8 (NPT1/8 optional)
- Temperature range: -20℃ to 80℃
- Piston material: Anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seal type: NBR seals (FKM available for high-temp)
- Protection class: IP54 (standard), IP67 (optional)
- Weight: 1.2kg ±5% (without accessories)
- Dimensions:
- Body length: 135mm
- Extended length: 150mm
- Width (flange to rod end): 62mm
- Height (mounting base): 42mm
High-precision stopper cylinder with integrated mechanical locking mechanism, featuring dual-position detection slots for sensor mounting. The TTG32X15R combines 3-stage position control (advance/stop/retract) with 0.03mm repeat positioning accuracy. Its hardened guide rod prevents side load deformation, making it ideal for precision alignment tasks.
- PCB board positioning in SMT assembly lines
- Workpiece clamping in CNC machining centers
- Precision stopping in automated conveyor systems
- Tool changing mechanisms in robotic arms
- Glass panel alignment in display manufacturing
Installation guidelines:
Maintain 0.5-1mm clearance between stopper face and target surface.
Use M5x0.8 mounting screws with 12N·m torque. Lubricate with ISO VG32
pneumatic oil. Avoid lateral forces exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | TTG32X15R |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Roller Type |
