Airtac UN54D Flame-Retardant Tube UN54D060040100MY
1. Single-layer construction with flame-retardant properties compliant with UL94 V-2 standards;
2. Superior elasticity with minimal bending radius for routing through confined spaces;
3. Enhanced water resistance and exceptional flexibility across operating temperatures;
4. Engineered for extreme abrasion resistance and high tensile strength performance.
Category: Auxiliary Components | Brand: AirTAC | Series: UN54D
AirTAC UN54D Flame-Retardant Tubing UN54D060040100MY Technical Specifications
- Full Model: UN54D060040100MY
- Series: UN54D Industrial Pneumatic Tubing
- Material: Nylon 12 (PA12) with flame-retardant additives
- Inner Diameter: 6.0 mm ±0.2mm
- Outer Diameter: 8.0 mm ±0.3mm
- Standard Length: 10 meters/roll
- Temperature Range: -40℃ to +120℃ (short-term 150℃)
- Flame Rating: UL 94 V-2 compliant
- Burst Pressure: ≥8.0 MPa
- Working Pressure: 0.8-1.5 MPa (recommended)
- Weight: 0.8 kg/roll (±5%)
- Coil Dimensions: Ø200mm (diameter) × 100mm (width)
- Color: Standard midnight blue with yellow tracer line
- Surface Resistance: 10^8-10^11 Ω (anti-static treated)
High-performance flame-retardant tubing featuring exceptional kink resistance and memory retention. The helical reinforcement structure maintains airflow integrity during bending while meeting strict industrial fire safety standards. Oil-resistant formulation prevents degradation from lubricant exposure.
- Robotic arm pneumatic circuits in automotive assembly
- Plastic injection molding machine air lines
- CNC machine tool coolant-resistant air supply
- High-temperature oven control systems
- Electronics manufacturing ESD-protected areas
Installation guidance:
Cut with rotary tubing cutter for clean edges. Minimum bending radius = 4×OD (32mm).
For high-vibration areas, use every 300mm with PCL-6 clamps (sold separately).
- Excellent resistance to: Hydraulic oils (ISO VG32/46), water glycol, compressed air contaminants
- Avoid continuous contact with: Strong acids, ketones, concentrated alkalis
| Property | Property Value |
|---|---|
| sku | UN54D060040100MY |
| Inner Diameter | 4.0mm |
| Wall Thickness | 1.00mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | 12mm |
| Length per Roll | Stroke 100mm |
| Burst Pressure @23°C | 4.0 |
